SINOTRUCK, Heavy duty truck, HOWO A7 Towing Truck, Tractor Truck

SINOTRUCK,Heavy duty truck, HOWO A7 Towing Truck, Tractor Truck
Company information:
We're one professional manufacturer which refitting special truck and trailer in China,established in 1969, more than 40 yrs producing experience, a growing enterprise with endless innovations and development.Our corporation mainly specializes in the various semi trailers and special vehicle related business, such as Dump Truck, tanker trailer, concrete mixer truck, and etc. Also, our business line ranges from the research, development, and design to the manufacture and sales for other automobile accessories, especially for axles and hydraulic cylinders. We'reone of the earliest company to get the approval of the ISO, CCC and Compulsory Product Certification Enterprises.We have exported more than 30 countries from 2005.Looking forward to your visiting or calling.


We keep good relations with main truck manufactrers in China. And we can supply all brands dump truck made in China. HOWO, SHACMAN, BEIBEN, DONGFENG, SINOTRUK, BEIBEN, FOTON, C&C, and so on. More details for these trucks, feel free to contact us please.



1.10 wheels
2. Capacity: 40-100MT
3. Engine: 340, 380, 420HP
4. Engine tech: Steyr tech, MAN tech
5. Clutch model: 430mm, single plate, dry, diaphragm
6. Gearbox Model: FAST 12JS160TA transmission
7. Rear Axle: AC16 double reduction axle
8. Rear Axle speed ratio: 4.111, 4.875
9. Wheel & tire: 12R22.5/ 12.00R20, Model 18Ply Rating
10. Axle base: 3150+1350
11. Fuel Tank: 400/500 L

12. Overall dimensions Length: 6793mm
13. Width: 2490mm
14. Height: 3525mm
Mass
Parameter Curb weight (kg): 8750
Max. Uthorized towed weight: 80000.
Color, red
NOTE:
We are a leading special purpose vehicle & vehicle body manuifacturer from China, our products: Refrigerated truck & body, Insulated truck & body, Dry Cargo truck & body, Store/stake truck & body, Explosion-proof truck & body, Dump truck & body, Truck crane & body, Mobile catering truck & body, Mobile stage truck & body, Mobile shop, Mobile kitchen, Cargo van, Medical waste transport truck & body, etc.

Engine Model	WP10.340,380,420	Engine power	340HP, 420HP,380HP
Engine capacity	9726,11975	Engine manufacturer	SINOTRUK
Combustion types	Diesel	Transmission	10,12
Dimensions(mm)	6875× 2493× 3160		× ×
The total mass(kg)		In the quality of the utilization factor	0
Curb mass(kg)	8750	Rated contained mass
Trailer total mass(kg)		Semi-trailer carrying saddles the maximum allowable weight
Approach / departure angle (° ):	21/56 27/60	Front overhang / Rear overhang(mm)	1375/800 1493/800
Wheelbase(mm)	2950+1350 3150+1350	Axle-load	6920 18000
Shaft number	3	Maximum speed(km/h)	103,98
Oil Consumption	, , , , ,	Spring	3/3
The number of tires	10	Tire specifications	12R22.5, 12.00R20
Front track	1914 2020 1939	Rear track	1847/1847

alltypes trucks, semitrailers,lowbedsemitrailer,containertransportsemitrailer,sidewallsemitrailer,storehousebarseries,vanseries,carcarriersemitrailer,dumptrailer,tankertrailerseries,concretemixertruckseriesetc.Also,ourbusinesslinerangesfromtheresearch,development,anddesigntothemanufactureandsalesforotherautomobileaccessories,especiallyfortires.OurproductsaremainlyexportedtoPhilippine,Tunisia,Vietnam,Tanzania,Angola,Mongolia,Venezuela,UAE,Kenya,ect

1)Manufacturer,morethan14yrsprofessionalexperience.
2)CCC,SGSandISO9001certificate,one year guaranteetermprovided.
3)Smallordercanbeaccepted.
4)Anycolorandlogowillbeavailable.
5)Productscanbecustom-madeaccordingtoyourdesign,ordiversifiedneeds.
