50 Tons Cement Tank Semi Trailer

  • 50 Tons Cement Tank Semi Trailer
  • USD 12500.27 /Unit
  • 1 Unit
  • 35 Unit
  • 27 days
Product Description
China 50 Tons Cement Tank Semi Trailer

50 Tons Cement Tank Semi Trailer50 Tons Cement Tank Semi TrailerBulk cement tanker trailer, is specially designed for bulk powder cargo transportation, like cement, corn, wheet, and other grains. Round cylinder design is good for fast-speed discharging(3-4 discharging outlets) and container transportation ( tanker body and chassis can be seperately loaded into contaier and conncetec by bolts and nuts).
Capacity: 40CBM
Manhole Cover: Alluminum manhole cover
Air compressor: 9.5CBM air compressor
Engine: Disel engine or electrical motor-optional.

Chassis: Special designed chassis for heavy duty and extra durability
Axle: German style(BPW, L1, etc) or American type.
Suspension: Mechanical suspension or air suspension-upon requirement
Landing Gear: 28T, two speeds.
King Pin: 2"or 3.5" bolt-in King pin.
50 Tons Cement Tank Semi Trailer
50 Tons Cement Tank Semi Trailer
50 Tons Cement Tank Semi Trailer
50 Tons Cement Tank Semi Trailer


cement tank Model
HTC9370GSN
dimension: (mm)11950mmx2500mmx3900mm
Tare weight13700kg
tank volume40cbm
wheelbase6900+1305+1305
tank thicknesstank body 6mm
Max Payload50Tons
overall weight50T
Unloading rate(KGS/MIN)above 1200KGS
frame and running constructon
AxleFUWA /3 (13T type)
tyrecustomized
rim8.0-20/12
leaf-spring80width*10pieces*13mm/6 sets
side beamcustomized

Kingpin

JOST ,two speed
Electrical and braking system
Electrical system24 volt electrical system.7 pin electrical connector. Parking .stop,reverse,number plate and indicator lights. rear light, rear front and side reflectors
Paint (shot blasting )Chassis is comletely shor blasted to SA 2.5 grade,and painted with first layer of international Zinc Epoxy primer(30 Microns DEF),second layer international high built polyurethane under coat(40 microns dft),third and forth layers international alkyd finish top coat.total 100 microns.
Seawater proofed,waxed,
power system(engine and air-compressor)
engineDiesel engine,Weifang 4102 type
Air-compressor10/2 doule cylinder

Product Images
50 Tons Cement Tank Semi Trailer Images 1
