/Semi Dump Trailers Mechanical Suspension for Goods Transporting
- USD 11700.40 /Unit
- 1 Unit
- 77 Unit
- 23 days
Product Description
Semi Dump Trailers Mechanical Suspension for Goods Transporting
Company information:
We're one professional manufacturer which refitting special truck and trailer in China,established in 1969, more than 40 yrs producing experience, a growing enterprise with endless innovations and development.Our corporation mainly specializes in the various semi trailers and special vehicle related business, such as Dump Truck, tanker trailer, concrete mixer truck, and etc. Also, our business line ranges from the research, development, and design to the manufacture and sales for other automobile accessories, especially for axles and hydraulic cylinders. We'reone of the earliest company to get the approval of the ISO, CCC and Compulsory Product Certification Enterprises.We have exported more than 30 countries from 2005.Looking forward to your visiting or calling.
We keep good relations with main truck manufactrers in China. And we can supply all brands dump truck made in China. HOWO, SHACMAN, BEIBEN, DONGFENG, SINOTRUK, BEIBEN, FOTON, C&C, and so on. More details for these trucks, feel free to contact us please.
35-50tons U Shape Self Dump Trailer
U shape Dump Trailer, Tipper Trailer, U Shape Tipper Trailer, and so on.
35-50tons U Shape Self Dump Trailer
Dump tipping semi trailer, 3 axles, is specially designed for heavy good transportation, like stone and mining materials. It is strong enough to carry up 80T in long distance delivery, rough road situation. France technical.
Tare Weight: 8500-115000 Kg
Dimension (Lx W X H): 10.5X2.5X1.8m
Capacity: 18, 24, 32, 45 CBM
Payload: 40-70T
Side WWall: 6mm strengthened wall
Front Wall: 8mm strenthened
Floor: 8mm strenthened
Hydraulic HYVA hydraulic cylinder
Chassis: Heavy Duty I Beam Chassis
Axle: BPW, FUWA, SAF-Optional
Suspension: Mechanical, Air Bags-Optional
King Pin 2", 3.5"
Tire: 11R22.5, 12R22.5. 315/80R22/5, 1200R20
Braking System: WABCO Relay Valve
Accessories: One standard tool box.
Q: How can we trust your company?
A: We are the official authority company by CIMC, SINOTRUK & FAW Qingdao Automobile Company. And we are registered in the Commercial Department of China, with the whole qualification for exporting, you would feel relax and safe to do business with us.We also have cooperated several times with the third party named TCI from UK. They can inspect the trucks and trailers producing and shipping after getting your authorization. We are your reliable partner.
Q: Can u provide the ISO9001 certificate or some others related?
A: Yes. We have been exporting trucks for years. Rich experience for exporting to different countries, African market, Russia, South America, this help us better know have to handle with different certificates needed.
Q: How about warranty item?
A: We could support u original spare parts. And also email or telephone assist in the following days. If necessary, for large quantity ordered, our engineer could go for technical assist.
Spec of 3Axles 40tons dump semi Trailer
Company information:
We're one professional manufacturer which refitting special truck and trailer in China,established in 1969, more than 40 yrs producing experience, a growing enterprise with endless innovations and development.Our corporation mainly specializes in the various semi trailers and special vehicle related business, such as Dump Truck, tanker trailer, concrete mixer truck, and etc. Also, our business line ranges from the research, development, and design to the manufacture and sales for other automobile accessories, especially for axles and hydraulic cylinders. We'reone of the earliest company to get the approval of the ISO, CCC and Compulsory Product Certification Enterprises.We have exported more than 30 countries from 2005.Looking forward to your visiting or calling.
We keep good relations with main truck manufactrers in China. And we can supply all brands dump truck made in China. HOWO, SHACMAN, BEIBEN, DONGFENG, SINOTRUK, BEIBEN, FOTON, C&C, and so on. More details for these trucks, feel free to contact us please.
35-50tons U Shape Self Dump Trailer
U shape Dump Trailer, Tipper Trailer, U Shape Tipper Trailer, and so on.
35-50tons U Shape Self Dump Trailer
Dump tipping semi trailer, 3 axles, is specially designed for heavy good transportation, like stone and mining materials. It is strong enough to carry up 80T in long distance delivery, rough road situation. France technical.
Tare Weight: 8500-115000 Kg
Dimension (Lx W X H): 10.5X2.5X1.8m
Capacity: 18, 24, 32, 45 CBM
Payload: 40-70T
Side WWall: 6mm strengthened wall
Front Wall: 8mm strenthened
Floor: 8mm strenthened
Hydraulic HYVA hydraulic cylinder
Chassis: Heavy Duty I Beam Chassis
Axle: BPW, FUWA, SAF-Optional
Suspension: Mechanical, Air Bags-Optional
King Pin 2", 3.5"
Tire: 11R22.5, 12R22.5. 315/80R22/5, 1200R20
Braking System: WABCO Relay Valve
Accessories: One standard tool box.
Q: How can we trust your company?
A: We are the official authority company by CIMC, SINOTRUK & FAW Qingdao Automobile Company. And we are registered in the Commercial Department of China, with the whole qualification for exporting, you would feel relax and safe to do business with us.We also have cooperated several times with the third party named TCI from UK. They can inspect the trucks and trailers producing and shipping after getting your authorization. We are your reliable partner.
Q: Can u provide the ISO9001 certificate or some others related?
A: Yes. We have been exporting trucks for years. Rich experience for exporting to different countries, African market, Russia, South America, this help us better know have to handle with different certificates needed.
Q: How about warranty item?
A: We could support u original spare parts. And also email or telephone assist in the following days. If necessary, for large quantity ordered, our engineer could go for technical assist.
Spec of 3Axles 40tons dump semi Trailer
| Type | 3 axles 40T Utype rear tipper semi trailer |
| Total size | 10000x2500x3000mm |
| Weight | |
| Loading capacity kg | 40000 |
| Tare weight kg | 11000 |
| Specification | |
| Main Beam | Heavy duty and extra durability designed Ibeam; opting for high tensile steel Q345, welded by automatic submerged-Arc processes. Top flange 20mm,width200mm;Middle Flange 10mm;bottom flange 20mm,width 200mm |
| Axle number | 3 |
| Axle weight load | 13Ton |
| Axle brand | FUWA |
| Suspension | Mechanical suspension America type |
| Leaf spring | Leaf spring 10pcs |
| Floor | Bottom plate 8mm .side wall 6mm |
| Tire type | 12R22.512pcs standard brand |
| Wheel rim | 9.0-22.5 |
| kingpin | 3.5'' bolt-in king pin |
| Landing gear | FUWA brand two-speed, manual operating ,heavy duty landing gear 28t |
| Cylinder | HYVA 214-7130 |
| Vehicular applications | Sand and pebble and mineral transport |
| Braking system | WABCO RE6 relay valve ;T30/30 spring brake chamber;40L air tanks |
| Tools box | 2 |
| Electrical | |
| Voltage | 24V |
| Receptacle | 7 ways (7 wire harness) |
| Light | |
| Side marker lamp | LED type |
| Shipping terms | Naked |
| Deliverytime | 20 workdays after confirming order and receiving your deposit |
