35-50tons U Shape Dump Trailer

35-50tons U Shape Self Dump Trailer

Company information:
We're one professional manufacturer which refitting special truck and trailer in China,established in 1969, more than 40 yrs producing experience, a growing enterprise with endless innovations and development.Our corporation mainly specializes in the various semi trailers and special vehicle related business, such as Dump Truck, tanker trailer, concrete mixer truck, and etc. Also, our business line ranges from the research, development, and design to the manufacture and sales for other automobile accessories, especially for axles and hydraulic cylinders. We'reone of the earliest company to get the approval of the ISO, CCC and Compulsory Product Certification Enterprises.We have exported more than 30 countries from 2005.Looking forward to your visiting or calling.


We keep good relations with main truck manufactrers in China. And we can supply all brands dump truck made in China. HOWO, SHACMAN, BEIBEN, DONGFENG, SINOTRUK, BEIBEN, FOTON, C&C, and so on. More details for these trucks, feel free to contact us please.


U shap Dump Trailer, Tipper Trailer, U Shape Tipper Trailer, and so on.

35-50tons U Shape Self Dump Trailer
Dump tipping semi trailer, 3 axles, is specially designed for heavy good transportation, like stone and mining materials. It is strong enough to carry up 80T in long distance delivery, rough road situation. France technical.

Tare Weight: 8500-115000 Kg
Dimension (Lx W X H): 10.5X2.5X1.8m
Capacity: 18, 24, 32, 45 CBM
Payload: 40-70T

Side WWall: 6mm strengthened wall
Front Wall: 8mm strenthened
Floor: 8mm strenthened
Hydraulic HYVA hydraulic cylinder

Chassis: Heavy Duty I Beam Chassis
Axle: BPW, FUWA, SAF-Optional
Suspension: Mechanical, Air Bags-Optional
King Pin 2", 3.5"
Tire: 11R22.5, 12R22.5. 315/80R22/5, 1200R20
Braking System: WABCO Relay Valve
Accessories: One standard tool box.




Q: How can we trust your company?

A: We are the official authority company by FAW Qingdao Automobile Company. And we are registered in the Commercial Department of China, with the whole qualification for exporting, you would feel relax and safe to do business with us. We are your reliable partner.



Q: Can u provide the ISO9001 certificate or some others related?

A: Yes. We have been exporting trucks for years. Rich experience for exporting to different countries, African market, Russia, South America, this help us better know have to handle with different certificates needed.



Q: How about warranty item?


A: We could support u original spare parts. And also email or telephone assist in the following days. If necessary, for large quantity ordered, our engineer could go for technical assist.

Model		tri-axle U shape self dump trailer
axle		16 tosn three units
tire		12R22.5
capacity		80 tons
