45m3 Four- Axle Cement Tanker Semi-Trailer

45M3 FOUR- AXLE CEMENT TANKER SEMI-TRAILER Model: WL9403GSN
Overall Length: 11,000 mm
Overall Width: 2,500 mm
Overall Height: 3,994 mm

TANK:
Loading Capacity : 54T (45M3)
Compartment: single
Material : Carbon steel
Discharging Hose Diameter : 4"
Discharging valve 4" butterfly valve
Discharging Hose Length : 7,000 mm
Hose quick coupling : 4" female quick coupling.
Discharging capacity : ≥1m3/min
Working pressure : 0.2 Mpa
Test pressure : 0.3 Mpa
Manhole: THREE
MAX. Horizontal Discharging Distance: 5,000 mm
MAX. Vertical Discharging Distance : 15,000 mm
RUNNING GEAR:
Suspension : Undermount tri-axle suspension with equalizer;
10-Leaf Spring + one axle lifting at the back.
Axle: FUWA 13Tx4PCS
Lifting height of rear axle: ≥75mm
Brake: Dual line pneumatic brake system.
Parking Brake : Type 30/30 spring brake system on two axles.
Wheel: 8.0-20, 10 holes steel Disc wheel, 16 Pcs.
Tire: 11R20 STEEL RADIUS TYRE, 16 Pcs
King Pin: 2"
LANDING LEG: Two speed manual operation type with sand shoe.

PNEUMATIC SYSTEM:
Engine: without
Air Compressor: without
With air suspension and one axle lifting at the back

ELECTRICAL:
Voltage: 24 Volt.
Receptacle: 7 ways
Light: Front Marker Lamp: White
Side Marker Lamp: Amber
Rear Lamp: Red
Turn Signal Lamp: Amber
STRUCTURAL WEIGHT RATING:
Tare Weight: 12,000 Kg
Pay Load: 54,000 Kg.
G.V.W.R.: 66,000 Kg.

PAINTING:
As per client's requirement
Note : all the details not mentioned above should comply with Chinese regulations.
