35m3 Two- Axle Cement Tanker Semi-Trailer

35M3 TWO- AXLE CEMENT TANKER SEMI-TRAILER
SPECIFICATION:
Overall Length: 10465 mm
Overall Width: 2,500 mm
Overall Height: 3, 650 mm
Wheelbase: 6,985+1500 mm

TANK:
Loading Capacity: 35M3
Compartment: single
Tank shell: Q345, 4mm thickness,
Dished ends: Q345, 4mm thickness
Air inlet: Via 4 inches male quick coupling
Pipe material: Carbon steel
Discharging Hose Diameter: 4 inches
Discharging valve: Single butterfly valve discharge with 100mm bellmouth ends at the rear
Discharging Hose Length: 7,000 mm
Hose quick coupling: 4 inches female quick coupling.
Discharging capacity: ≥1m3/min
Working pressure: 0.2 Mpa
Test pressure: 0.3 Mpa
Manhole: TWO
MAX. Horizontal Discharging Distance: 5,000 mm
MAX. Vertical Discharging Distance : 15,000 mm

RUNNING GEAR:
10-Leaf Spring.
Axle: FUWA (inboard brake drum) 13T X2 PCS
Brake: Dual line pneumatic brake system.
Parking Brake : Type 30/30 spring brake system on two axles.
Disc: 9.0-22.5, 8Pcs.
Tire: 12R22.5 tubeless radial tyres, 8 Pcs
King Pin: 2 inches
Landing leg: Two speed manual operation type with sand shoe.


ELECTRICAL:
Voltage: 24 Volt.
Receptacle: 7 way
Light: Front Marker Lamp: White
Side Marker Lamp: Amber
Rear Lamp: Red
Turn Signal Lamp: Amber

STRUCTURAL WEIGHT RATING:
Tare Weight: 11,000 Kg
Pay Load: 42,000 Kg.
G.V.W.R. : 53,000 Kg.

PAINTING:
Colour: customer corporate color and logo.
Note:all the details not mentioned above should comply with Manufacturer's Standard.
