40m3 Cement Tanker Semi-Trailer Powder Tank
- USD 18000.22 /Unit
- 1 Unit
- 71 Unit
- 26 days
Product Description
40m3 Cement Tanker Semi-TrailerPowder Tank (WL9400GSN) | ||
40m3 Dry Bulk Tank with Three Axles | ||
Parameter | Dimension(mm) | 12000*2500*3741 |
Loading Capacity(kg) | 40m3 | |
Tank Thickness | 6mm | |
Bulkhead Thickness | 6mm | |
Max. Horizontal Discharging Distance | 5000mm | |
Max. Vertical Discharging Distance | 15000mm | |
OEM | Compartment | 1 compartments |
Tyre | 12 units,11R20 | |
Rim | 12 units,8.0-20 | |
Landing Gear | single operation | |
King Pin | 90#,assembled | |
Axle | 3units,13T FUWA | |
Suspension | mechanical suspension | |
Manhole | 3 units | |
Discharging Valve | 2 units, 4''butterfly valve | |
Discharging Hose Length | 7,000mm | |
Discharging Hose Diameter | 4'' | |
Discharging Capacity | ≥ 1m3/min | |
Pneumatic System | Air Compressor | Suzhou 12/2 |
Diesel Engine | Kefa 4102 | |
Electromotor | 4100 Made in China, (44Kw, 2000r/Min) | |
Air Compressor | 10m3/min Made in China, | |
Mounted at the front of trailer, | ||
Others | Fire Extinguisher | 2 units |
Air Reservoir | 2 units | |
Tool Box | 1 unit,0.8m | |
Spare Tyre Carrier | 2 units | |
ELECTRICAL | Voltage | 24 Volt. |
Receptacle | 7 way | |
Light | Front Marker | |
Side Marker Lamp | Amber | |
Rear Lamp | Red | |
Turn Signal Lamp | Amber | |
We can design the model according to your special requirements. We are Manufacturer, Certificate ISO9001, CCC, quality assured, high strength chassis, Heavy duty and extra durability designed. | ||
Product Images
