45m3 Triple Axle Cement Tanker Semi-Trailer
- USD 22000.25 /Unit
- 1 Unit
- 16 Unit
- 30 days
Product Description
45M3 TRIPLE AXLE CEMENT TANKER SEMI-TRAILER
Specification
Model | WL9403GSN |
Overall Dimension | 10,770*2,500*3,900(Lx W x H)(mm) |
Wheelbase | 6,700+1,310+1,310 (L*W*H) (mm) |
Weight(Kgs) | Theoretic Tare Weight: 8,700 |
Payload: 54,000 | |
Gross Vehicle Weight: 64,000 | |
Tanker | Loading Capacity: 45m3 (54T) Compartment: single Material: Q235 Manhole: Three, with aperture lump filter bucket Discharging Hose Diameter: 4" Discharging valve: 5" butterfly valve Hose quick coupling: 4" female quick coupling. Discharging capacity : ≥1m3/min Working pressure: 0.2 Mpa Max. Horizontal Discharging Distance: 5,000 mm |
Compressor | Compressor: JIN HUENG(QINGDAO TAIKE) model VS 260-14 mounted on tractor truck chassis |
Suspension | 3 axle with 9 pcs of spring leaves suspension, |
Axle | FUWA 13T, 3 pcs |
Tire | 295/80R22.5, 12pcs,triangle brand |
Kingpin | 3.5" |
Landing Gear | JOSTC200T |
Brake system | Dual line pneumatic brake system |
Electrical system | 1. Voltage: 24v 2. Receptacle: 7 ways (7 wire harness) |
Tail lamp with turn signal, brake light & reflector, side lamp etc. | |
One set 6-core standard Cable. | |
Painting | Surfaces and accessories are made smooth and then cleaned with a mixture of chemicals before the painting; Steel blasting completely; Zinc-rich Primer Painting + Surface Painting; Painting in colors in according to customer. |
Packing | In Nude |
The manufacturer reserves the right of technical alteration/change for better improvement without prior notice! |
Product Images
