Sinotruk HOWO 6X6 371HP Tractor Truck
- USD 50000.55 /Unit
- 1 Unit
- 34 Unit
- 23 days
Product Description
| Specifications HOWO 6*6 SERIES TRACTOR TRUCK | |||
| Model | ZZ4257N3557A | ||
| Engine | Make: SINOTRUK | ||
| Diesel 4-stroke direct injection diesel engine | |||
| Engine model: WD615.47, Euro II emission standard | |||
| 6-cylinder in-line with water cooling, turbo-charging and intercooling | |||
| Maximum output: 371 hp (272 Kw) at 2200 rpm | |||
| Maximum torque: 1460 Nm at 1300-1600 rpm | |||
| Number of cylinder: 6 | |||
| Displacement: 9.726 L | |||
| Specific fuel consumption: 195 g/kWh | |||
| Engine oil filling quantity: 19 l | |||
| Cooling system filling quantity (long-term filling): 40 l | |||
| Thermostat with 71ºC opening begin | |||
| Twin cylinder air compressor | |||
| Rigid fan | |||
| Transmission | HW19710, 10 forwards and 2 reverse | ||
| Ratio: 14.28 10.62 7.87 5.87 4.375 3.26 2.43 1.8 1.34 1 13.91(R1) 3(R2) | |||
| Propeller Shaft | Double universal joint propeller shaft with gear-shaped coupling flange | ||
| Front Axle | Double steel front steering drive axle with planetary wheel reduction, Ratio:5.73 | ||
| Rear Axle | ST16, Steel front steering driving axle, central single reduction with hub reduction and with differential locks between wheels and axles . | ||
| Ratio:5.73 | |||
| Chassis | frame: U-profile parallel ladder frame with section of 243x80x8mm, and reinforced subframe all cold riveted cross members | ||
| Aluminium fuel tank: 400 L capacity with locking fuel cap, fitted to the off side of the chassis | |||
| Clutch | Reinforced diaphragm clutch, 430mm | ||
| Steering | ZF power steering, modol ZF8098, hydraulic steering with power assitance | ||
| Transfer Case | Model: ZQC 2000 | ||
| High-grade/low grade ratio: 0.89/1.536 | |||
| Brakes | Service brake: dual circuit compressed air brake | ||
| Parking brake (emergency brake): spring energy, compressed air operating on front shaft and rear wheels | |||
| ABS control system: Exists | |||
| The fifth wheel | Size: 3.5" Option: 2" | ||
| Loading capacity at the fifth wheel: 22,645kg | |||
| Wheels & Tyres | Tire: 12.00R20, all steel radial tire | ||
| Option:14.00-20, 14.00R20 | |||
| Driver's Cab | HW76 Cab, with two seats and single bed, 2-arm windscreen wiper system with three speeds, | ||
| damped adjustable driver's seat, with heating and ventilating system, exterior sun visor, safety belts, adjustable steering wheel, air horn, | |||
| air conditioner , with transverse stabilizer,with 4-point support fully floating suspension + shock absorber | |||
| Electrics | Operating voltage: 24 V, negative grounded | ||
| Starter: 24 V, 5.4 Kw | |||
| Alternator: 3-phase, 28 V, 1500 W | |||
| Batteries: 2 x 12 V, 165 Ah | |||
| Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light | |||
| Instrument Panel | Active check central controllor with indicators, with this integral instrument the daily manual checks on the vehicle and combined indicators | ||
| of compressed air pressure, coolant temperature, engine oil pressure and battery charging | |||
| Dimensions mm | Wheel base | 3500+1400 | |
| Front wheel track | 1830 | ||
| Rear wheel track | 1830 | ||
| Front overhang | 1578 | ||
| Rear overhang | 700 | ||
| Approach angle (0) | 32 | ||
| Departure angle (0) | 74 | ||
| Overall length | 7178 | ||
| Overall width | 2496 | ||
| Overall height | 3146 | ||
| Weight kg | Dead weight | 9800 | |
| Gross vehicle weight | 33000 | ||
| Gross combination weight | 70000 | ||
| Front axle loading capacity | 7000 | ||
| Rear axle loading capacity | 2*13000 | ||
| Performance | Maximum driving speed (km/h) | 85 | |
| Minimum ground clearance (mm) | 298 | ||
| Fuel consumption (l/100 km) | 38 | ||
| The manufacturer reserves the right of technical alteration/change for better improvement without prior notice! | |||
