Sinotruk Hohan 4X2 336HP Zz4185n3613b1 Tractor Truck

SINOTRUK HOHAN/ZZ4185N3613B1 High Roof Tractor Truck

HOHAN is a powerful and stable towing truck model with low oil consumption, high reliability and low dead load, with multiple customization options available for the users. The newly-designed driving cab of HOHAN is luxuriously completed, elegant, safe and comfort, optimized for different operation environments, accommodating the varied user demands, making it a favorable choice for long-range standard-load high transportations and medium/short-range transportation tasks.

HOHAN 336HP 4X2 TRACTOR TRUCK
MAIN SPECIFICATION
Description		HOHAN 336HP 4X2 TRACTOR TRUCK
Model		ZZ4185N3613B1
Engine Power		336HP
Loading Capacity		12200Kgs
Place of Origin		China
DETAIL SPECIFICATION
Cabin	Model	H17
Engine	Model	D615.69
	Horse Power (Hp/rpm)	336/2200
	Type	Euro II
Clutch		Φ430 pull-type diaphragm clutch
Transmission		HW13710
Front Axle		H153
Driving Axle		H457 Ratio: 4.875
frame(mm)		270x85X10
Steering System		D50
Tire		295/80R22.5
Fuel Tank Capacity (L)		350
Vehicle Weight (kg)		5,800
Gross Vehicle Weight (kg)		18,000
Rated Loading Capacity(kg)		12,200
Overall Dimension(L*W*H)(mm)		6175×2496×3700
Wheelbase(mm)		3600
Wheel Track(Front/Rear)(mm)		2022/1830
Approach/Departure Angle(°)		21/19
Max. Speed (km/h)		110
