Sinotruk HOWO T7h 6X2 320HP Tractor Truck

SINOTRUK HOWO T7H 6X2 320HP Tractor Truck


HOWO-T7H inherits the excellent HOWO characteristics of high suitability and cost performance demand of China and other developing countries. On the basis of HOWO-A7, matching MAN' technology engine, single reduction axle and other assembly parts, vehicle reliability, economic, technical indicators have reached the excellent level. The vehicle matching design focus concerned about the reliability of the product, the economy, security, environmental protection.The market positioning is updated Chinese heavy duty truck.
T7H series truck contains full kinds of vehicle types and has complete spectrum, including: tractor,cargo, tipper,concrete mixer and other special vehicles adapted on its chassis.
Driven type: 4x2, 6x2,6x4,8x4,etc.
Power range: 270 PS- 460PS.


Advantages:
·Reliable and high quality: adopting the design philosophy of Germany, cooperating with high-level supplier; The kilometre interval of vehicle overhaul is up to 1.5 million, much more than the competitive products
·Fuel economy: low fuel consumption engine+ efficient and small speed radio driving axle+ using the tech of Germany, 5-9% less than competitive trucks.
·Safety: With the active and passive security the same as the world's greatest truck; The cab impact performance is increased by 15% according the standard of Sweden.
·Beautiful and comfortable cab: More beautiful and comfortable than HOWO A7.

Main Technological Parameters
Cab		Extended cab, double berth, up/down and front/back adjustable steering wheel, VDO instrument and control module, double locking safety belt, exterior sun visor.
Engine	Model	MC11.32-40
	Rated power KW/rpm	320HP
	Maximum torque Nm/ rpm	1600/1100-1400
	Displacement L	10.518
	Type	Six cylinders inline, water cooling, 4-stroke, supercharging intermediate cooler, high pressure and common rail
Transmission		SINOTRUCK HW series 16 gears transmission, transmission with main and auxiliary transmission structure, main transmission with double countershaft, auxiliary transmission with planetary reduction.
Front axle		HF7, rated load of 7t, drum-type; heavy; load truck with HF9 drum-type, rated load of 9t.
Drive axle		MCY13Q central single stage reduction
Suspension		Front and rear leaf spring suspension, front suspension with shock absorber, transverse stabilizer, and rear suspension is disconnected type with transverse stabilizer.
Steering system		ZF8098 steering gear, ZF steering oil pump, system pressure 18MPa
Braking system		Service brake: dual-circuit air pressure brake; parking brake; spring storage energy without air; auxiliary brake: engine exhaust braking; standard engine EVB, with ABS and optional auto clearance adjusting arm.
Tire		11.00-20,12.00-20
Tank volume L		400
Gross mass kg		35000
Rated load kg		18000
Complete vehicle external dimensions ( length*width*height) mm		6840*2496*3850
