Beiben 4X2 Tractor Head Northbenz Trailer
- USD 36890.00 /Unit
- 1 Unit
- 80 Unit
- 10 days
Product Description
Beiben 4x2 Tractor Head Northbenz Trailer
Top quality famous North Benz tractor head. Mercedes Benz technology, excellent performance, resonable price.
Certificate: ISO9001, CCC, GBJ9001A-2001
Traction type: 6x4
Driving type: LHD(RHD is optioned)
Cabin:
North Benz long cabin, one sleeper, A/C
Radio player(with USB), Safety belt, Adjustable air type, high back and shock absorption
Driver seat with handle and seatbelts
Dash board with all necessary gauges such as (km meter, rpm, oil pressure, temperature, air pressure,
Fuel level)
Headlight, Sun protection on cabin.
Engine:
Engine brand: Weichai
Engine model: WP10.380E32 EURII EGR
Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line
With water cooling, turbo-charging & inter-cooling with exhaust valve brake.
Displacement: 11.596 liters
Max. Output: 380HP@353kW
Max torque: 1970NM@1200-1500rpm
Bore/Stroke(mm): 126/155
Clutch:
Clutch: Φ 430 Diaphragm type
Type: Single dry frictional disc, Hydraulic boosting
Gear box:
Model: Fuller 12 speeds(12JS200T), manual, 12-forward and 2 reverse speeds
Steering:
TAS85
Brake system:
Double-circulate brake system
Axles:
Front axles: Mercedes Benz Technology 7.5 Tons
Rear axles: Benz double Reduction driving axle, Ratio: 1: 5.921(option5.263, 6.733)
frame: Strengthened frame 317x70x8.5+7+8mm(E380TM)
Tyre: 12.00R20
No tyre: 10+1 spare
Spring:
13/13
Fuel tank capacity (L):
400
Weight:
Kerb. Mass: 9200 kg
Towing mass: 25000kg
Dimensions:
Wheel base (mm): 3450+1450
Front overhang (mm): 1410
Rear overhang (mm): 625
Front track (mm): 1995
Rear track (mm): 1800
Max. Length(mm): 6935
Max. Width(mm): 2495
Max. Heigh(mm): 3340
Performance:
Max. Speed (km/h): 100
Approach angle: 20 degree
Departure angle: 64 degree
Max. Gradeability(%): 30
Fifth Wheel: 50#
1. After-sale Service
Any small question will be solved at the most prompt time. We also offer relative technical support. Our spare parts will be available at any time after your order.
2. Supply Capacity
We manufacture the truck as soon as your order comes. And for the stock, we can delivery it immediately.
3. For more details, please just feel free to contact me.
Top quality famous North Benz tractor head. Mercedes Benz technology, excellent performance, resonable price.
Certificate: ISO9001, CCC, GBJ9001A-2001
Traction type: 6x4
Driving type: LHD(RHD is optioned)
Cabin:
North Benz long cabin, one sleeper, A/C
Radio player(with USB), Safety belt, Adjustable air type, high back and shock absorption
Driver seat with handle and seatbelts
Dash board with all necessary gauges such as (km meter, rpm, oil pressure, temperature, air pressure,
Fuel level)
Headlight, Sun protection on cabin.
Engine:
Engine brand: Weichai
Engine model: WP10.380E32 EURII EGR
Engine type: Diesel 4-stroke direct injection engine, 6-cylinder in-line
With water cooling, turbo-charging & inter-cooling with exhaust valve brake.
Displacement: 11.596 liters
Max. Output: 380HP@353kW
Max torque: 1970NM@1200-1500rpm
Bore/Stroke(mm): 126/155
Clutch:
Clutch: Φ 430 Diaphragm type
Type: Single dry frictional disc, Hydraulic boosting
Gear box:
Model: Fuller 12 speeds(12JS200T), manual, 12-forward and 2 reverse speeds
Steering:
TAS85
Brake system:
Double-circulate brake system
Axles:
Front axles: Mercedes Benz Technology 7.5 Tons
Rear axles: Benz double Reduction driving axle, Ratio: 1: 5.921(option5.263, 6.733)
frame: Strengthened frame 317x70x8.5+7+8mm(E380TM)
Tyre: 12.00R20
No tyre: 10+1 spare
Spring:
13/13
Fuel tank capacity (L):
400
Weight:
Kerb. Mass: 9200 kg
Towing mass: 25000kg
Dimensions:
Wheel base (mm): 3450+1450
Front overhang (mm): 1410
Rear overhang (mm): 625
Front track (mm): 1995
Rear track (mm): 1800
Max. Length(mm): 6935
Max. Width(mm): 2495
Max. Heigh(mm): 3340
Performance:
Max. Speed (km/h): 100
Approach angle: 20 degree
Departure angle: 64 degree
Max. Gradeability(%): 30
Fifth Wheel: 50#
1. After-sale Service
Any small question will be solved at the most prompt time. We also offer relative technical support. Our spare parts will be available at any time after your order.
2. Supply Capacity
We manufacture the truck as soon as your order comes. And for the stock, we can delivery it immediately.
3. For more details, please just feel free to contact me.
| SPECIFICATIONSFORTRACTORTRUCK | |||
| VehicleSpecifications | Model | ND41805A35J | |
| Traction4X2,6X4,8X4 | 4X2 | ||
| Power | 290HP | ||
| WeightParameter | CompleteVehicleKerbMass(kg) | 5800 | |
| Maximumauthorizedtotalmass(kg) | 35870 | ||
| DimensionParameter | ExternalDimensions(mm) | Length(mm) | 5995 |
| Width(mm) | 2495 | ||
| Height(mm) | 3095 | ||
| wheelbase(mm) | 3500 | ||
| PerformanceParameter | MaximumSpeed(km/h) | 110 | |
| MaximumGradeability(%) | 35 | ||
| Turningdiameter(m) | 16 | ||
| RecommendedConfiguration | Engine | EngineType | WP10.290E32 |
| Ratedpower(kW)/ Rev(r/min) | 213/2200 | ||
| Horsepower/(hp) | 290 | ||
| Torque(N*m)/Rev(r/min) | 1160/1600 | ||
| Transmission | 9JS119B | ||
| gearbox | 9forwardgears 1backwardgears | ||
| Clutch(mm) | 430 | ||
| Axle | FrontAxle | 7.5t | |
| RearAxle | 13t | ||
| Axleload-bearing | Frontaxle | 7.5t | |
| Frontaxle | 13t | ||
| FuelTank(L) | 400 | ||
| Track(mm) | 2045/1800,1838 | ||
| Frontoverhang/rearoverhang(mm) | 16/40 | ||
| Type | 11.00-20 18PR | ||
| Cabin | Sleeper | nonesleeper | |
| OTHER | ABS | optional | |
| COLOR | optional | ||
| Horsepower | 340HP,290,310,380, 420isoptional) | ||
| Type | nylon(radialand tubelessisoptional | ||
