Sinotruk HOWO T7h 480HP 4X2 Tractor Truck with Man Technology
- USD 43800.00 /Unit
- 1 Unit
- 50 Unit
- 19 days
Sinotruk HOWO T7h 480HP 4X2 Tractor Truck with Man Technology
HOWO T7H 4*2Tractor Truck with Stronger Materials and Cheap Price
1. Hydraulic cylinder HOWO T7H tractor truck
2. Loading 25ton-60ton capacity
3. Radial tire or Tubeless tire
4. Widely used to carry coal, mine, iron powder, steel slag, lime ash, stone, sand, wood etc
5. Suitable for good or bad road condition
6. Low fuel consumption, low pollution, high safety
Engine:
Make: SINOTRUK MAN
Diesel: 4-stroke direct injection diesel engine
Engine model: Euro II, Euro III, Euro IV emission standard; 6-cylinder in-line with water cooling, turbo-charging and intercooling
Maximum output: 336 HP, 375HP, 380HP, 420HP
Clutch:
Single-plate dry coil-spring clutch, diameter 420mm
Transmission:
Model: HW18709, synchromesh, 9 forward & 1 reverse; Option: 5S-150GP
Front Axle:
Steering with double T-cross section beam
Rear Axles:
Pressed axle housing, central single reduction with hub reduction and with differential locks between wheels and axles, Ratio: 5.73
Steering:
ZF power steering, model ZF8098, hydraulic steering with power assistance. Ratio: 20.2-26.2
Braking System:
Service brake: Dual circuit compressed air brake; Parking brake(emergency brake): Spring energy, compressed air operating on rear wheels; Auxiliary brake: Engine exhaust brake; Option: ABS
Wheels & Types:
Rims: 8.5-20, 10 hole-steel; Types: 12.00-20; Option: 12.00R20, 11.00-20, 11.00R20, 12R22.5
Cab:
Standard cab, all-steel forward control, 55° Hydraulically tiltable to the front, a-arm windscreen with casted-in radio aerial, hydraulically damped adjustable drivers seat and rigid adjustable co-drivers seat, with heating and ventilating system, exterior sun visor, adjustable roof flap, stereo radio and/cassette recorder, safety belts, adjustable steering wheel, air horn, air conditioner, with 4-point support fully floating suspension + shock absorbers
Electrical System:
Operating voltage24V, negative grounded; Starter: 24V, 7.5kw; Alternator: 3-phase, 28V, 1500W; Batteries: 2*12V, 165Ah; Cigar-lighter, horn, headlamps, fog lights, brake lights, indicators and reverse light; Option: 180Ah Batteries.
We are the first level agency for SINOTRUK whole tuck series, we can supply HOWO tractor trucks, HOWO Dump Trucks, HOWO concrete mixer trucks and special trucks, we can supply trucks for our clients with good quality and competitive price, because we get directly support from the CNHTC factory.
We also supply HOWO A7 series 4X2, 6X4 tractors and 6X4, 8X4 dump trucks etc. Which developed on the base of HOWO series, with higher equipment and performance.
Sinotruk HOWO 371hp 6X4 Tractor Truck | ||
MODEL | HOWO 6x4 TRACTOR TRUCK | |
Cab | Driving type | Left Hand Drive(RHD is optional) |
Cab type | HW76 flat roof cab with one sleeper bed,with A/C | |
Engine | Engine Model | WEICHAI WD615.47,371hp |
Type | 6-cylinder in-line with water cooling, supercharging & inter cooling | |
Displacement | 9.726L | |
Engine output | 371hp/2200 rpm | |
Max. torque | 1350 NM /1300-1600rpm | |
frame and equipments | Transmission (gear box) | HW15710,10 speed transmission |
Clutch | D430 Diaphragm type | |
Steering | ZF8098 | |
Front axle | HF7 drum type, 7tons | |
Rear axle | HC16 Double reduction Ratio=3.73 | |
Fuel tank | 400L | |
Tires | 12.00R20, 10+1spare | |
Weights in kg | Kerb. mass | 9180kg |
Total mass | 25000kg | |
Max.towed capacity | 40tons to 60tons | |
Performance | Max. speed (km/h) | 102 |
Max. gradeability(%) | 26 | |
Approach/departure angle | 16/70 degree | |
Dimension in mm | Overall dimension(mm) | 6800×2496×2958 |
Wheel base (mm) | 3200+1400 | |
Front/rear overhang (mm) | 1500/725 | |
Front /rear wheel track(mm) | 2022/1850 | |
Saddle joint surface height(empty/full) | 1360/1326 | |
Front /rear turning circle(mm) | 2790/2230 | |
Minimum ground clearance(mm) | 267 | |
Saddle size | 2''( 3.5'' is optional) |
