Tri-Axle 20FT 40FT Low Flatbed Low Flatbed Semi Trailer
- USD 12800.14 /Unit
- 1 Unit
- 37 Unit
- 26 days
1. ChengLi is professional in special vehicles manufacturing. We can supply all brands of special trucks, such as, Faw, Foton, Shaanxi, Sinotruck, JAC, JMC, Isuzu, Dongfeng.
2. The drive type includes 4X2, 4X4, 6X2, 6X4, 6X6, 8X4
3. We can design 30Ton-100Ton flatbed container trailer with air bag or spring suspesion.
4. We can provide LHD (left hand drive) or RHD (right hand drive) vehicles.
5.Chassis can be done Q345, T610, T700, Hardox 450 steel etc.
6. Our products are Widely used in chemical enterprise, oil depot, storehouse, shop and terminal market.
Chengli Special Automobile Co., Ltd, as the "Alibaba Group" in the special vehicle circle, has developed into the biggest professional special vehicle manufacturer of central China starting from scratch since 2004.
LPG tank is one of our most advantageous key products which ranks Top 5 in China, excellent engineers and high-grade production equipment as well as strict quality control system can ensure all the tank work well with 10-20 years use life.
Our main products:
1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck Mounted Crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water Truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage Suction Truck,
9. Cement Powder Tank truck/ Bulk Cement Truck
10. High-altitude operation truck,
11. Self-loading Garbage Truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer, Tipper Trailer, Side tipper / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
We sincerely welcome you to visit our factory and provide your precious suggestion for us!
BEST COMPETITIVE PRICE WITH TRUSTED QUALITY Factory
| 3 Axles low flatbed heay duty semi-trailer | |||
| Tare Weight(Kg) | 37050 | Overall Dimensions(LxWxHmm) | 15400x3000x2850 |
| Payload(Kg) | 25000 | Axles Load(Kg) | 21450 |
| Wheel base(mm) | 9550+1350+1350 | Rear Tread(mm) | 2180/2180/2180 |
| Specifications | |||
| I Beam& Chassis | Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 18mm,width 140mm; Middle Flange 8mm,Height 500mm, Bottom Flange 20mm,width 140mm. | ||
| Axle | 3 axles (BPW 13ton, FUWA, L1 brand are optional) | ||
| Suspension | Heavy duty mechanical suspension | ||
| Floor | 3mm checker plate | ||
| Leaf Spring | 13 piece Leaf spring | ||
| King Pin | JOST brand 2" Bolt-in King Pin | ||
| Landing Gear | JOST brand Two-speed, manual operating, heavy duty landing gear | ||
| Wheel Rim | 8.25-22.5steel wheel rim | ||
| Tire | 8.25-20,8.25R20 tire with one spare tire | ||
| Ramp | Mechanical ramp with spring | ||
| Braking System | WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 40L air tanks | ||
| Twist Lock | 12 nos. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container, the retractable central locks can be laid down. | ||
| Painting | Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint | ||
| Accessories | One standard tool box | ||
HubeiProvince,P.R.China
Export:Room3102,Block7,FanhaiInternationalSOHOTown,
JianghanDistrict,Wuhan,HubeiProvince,China
Tel/Fax:+86 027 8379 6298
Mob:(+86) 18607168573
Hubei Chengli Special Automobile Co., Ltd is a famous specialied manufacturer of trucks for Municipal environmental construction, virescence, petrol medicals, container. Semi-trailers, transportation in China.
We own export licenseand all our truckss have passed ISO9001, ISO16949, GJB9001A Quality Certification and China Compulsory Certification(CCC). Due to the reliable quality and excellent after-sales service, the Brand Chengliwei is popular to worldwide. The trucks has been shipped to Vietnam, Mongolia, Kazakhstan, Uzbekistan, Bangladesh, Korea, Russia, Afghan, Iraq, Angola, Algeria, Nigeria, Congo, Libya, Jordan, Ethiopia, Mozambique, Mali, Niger, Trinidad, Namibia, etc.
Chengli Special Automobile Co., Ltd consisit to insist with "Surviving by the quality, Developing by the reputation, Technology creating new path, Service creating new brand". We aim to" credit, pragmatic, innovative, progressive"， promote the quality, deveope and manufacture more and more special vehicles with good quality and competitive price.
1. Factory Supply:one of the biggest special purpose truck manufacturers in china,more than 300 kinds of special truck for your choice.
2. OEM Ability: according to your demand, material, dimensions, surface color and the logo are optional for you.
3. Good Quality: with ISO CCC BV certification Solid technology, advanced equipments; reliant quality and flexible modes of operation also have strict quality control system,passed the ISO9001-2008 and the 3C (China Compulsory Certification),our brand is china famous brand with good reputation in the market.
4. Best Service: 24-hour hotline and email during communication.
5. Fast Delivery: 5-10 days after payment(most common products), safe and quick delivery.
Packaging:nude with wax.
Shipping:Ro-Ro/Bulk Ship/Container
-
