Faw 6*4 Concrete Mixer Truck
- USD 54000.00 /Unit
- 1 Unit
- 17 Unit
- 12 days
Chassis | Brand | FAW | |
Chassis model | CA1250P66K2L2T1S2E | ||
Drive model | 6*4 | ||
Tire | 12.00R20 | ||
Brake | Air brake | ||
Engine | Model | CA6DL2-35E3 | |
Horse Power | 350 | ||
Displacement(ml)/Power(kw) | 8600/261 | ||
Emission | Euro II | ||
Main Parameter | Overrall dimension(MM) | L*W*H(MM) | 10020*2495*3950 |
wheelbase | 4300+1350 | ||
Axles No. | 3 | ||
weight | GVW | 45000 | |
Payload weight | 10280 | ||
Curb weight | 14670 | ||
Leaf spring No. | 12/12 | ||
Approaching/Departure Angle(°) | 24/18 | ||
Front/Rear trace(mm) | 2050 | ||
Front/Rear suspension(mm) | 1830/1830 | ||
Max speed(km/h) | 88 | ||
Gear box | 9speed | ||
Front/Rear Axle Load | 7/16T | ||
Technical Paratmeters of Mixing Tube | Tube Geometric Volume(M³) | 15 | |
Mixing Volume(M³) | 12 | ||
Filling Rate(%) | 58% | ||
Rate of Feeding(M³/min) | ≥3 | ||
Rate of Delivery(M³/min) | ≥2.0 | ||
The Remaining Rate(Ml³/min) | ≤1.0 | ||
Tube Service Speed(r/min) | 0~12 | ||
Tube Dip(°) | 13~15 | ||
Hydraulic Drive Paratmeners | Oil Pump | import from Italy | |
Hydraulic Motors | |||
Decelerator |
Chengli Special Automobile Co., Ltd is a professional manufacturer of all kinds of special truck and trailer as well as other special equipment.
LPG tank is our most advantage key products which rank Top 5 in China, excellent engineers and high-grade production equipment as well as stricted quality control system can ensure all the tank from us run very well with 10-20 years use life.
Our main products:
1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck Mounted Crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water Truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage Suction Truck,
9. Cement Powder Tank truck/ Bulk Cement Truck
10. High-altitude operation truck,
11. Self-loading Garbage Truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )
Should you have any other problems,pls feel free to contact us,or visit our web site.
We sincerely welcome you to visit our factory and provide your precious suggestion for us!
Contact person:Mike Wong
Mobile :86-15629116861
Hubei Chengli Special Automobile Co., Ltd is a famous specialied manufacturer of trucks for Municipal environmental construction, virescence, petrol medicals, container. Semi-trailers, transportation in China.
We own export licenseand all our truckss have passed ISO9001, ISO16949, GJB9001A Quality Certification and China Compulsory Certification(CCC). Due to the reliable quality and excellent after-sales service, the Brand Chengliwei is popular to worldwide. The trucks has been shipped to Vietnam, Mongolia, Kazakhstan, Uzbekistan, Bangladesh, Korea, Russia, Afghan, Iraq, Angola, Algeria, Nigeria, Congo, Libya, Jordan, Ethiopia, Mozambique, Mali, Niger, Trinidad, Namibia, etc.
Chengli Special Automobile Co., Ltd consisit to insist with "Surviving by the quality, Developing by the reputation, Technology creating new path, Service creating new brand". We aim to" credit, pragmatic, innovative, progressive", promote the quality, deveope and manufacture more and more special vehicles with good quality and competitive price.
1. Factory Supply:one of the biggest special purpose truck manufacturers in china,more than 300 kinds of special truck for your choice.
2. OEM Ability: according to your demand, material, dimensions, surface color and the logo are optional for you.
3. Good Quality: with ISO CCC BV certification Solid technology, advanced equipments; reliant quality and flexible modes of operation also have strict quality control system,passed the ISO9001-2008 and the 3C (China Compulsory Certification),our brand is china famous brand with good reputation in the market.
4. Best Service: 24-hour hotline and email during communication.
5. Fast Delivery: 5-10 days after payment(most common products), safe and quick delivery.
Packaging:nude with wax.
Shipping:Ro-Ro/Bulk Ship/Container
