Tri Axles Flatbed Wrecker/Flatbed Transportation Trucks

Tri-Axles flatbed heay duty truck/Flatbed Wrecker/Flatbed transportation trucks/towingtruckwrecker

3 Axles flatbed heay duty truck
Tare Weight(Kg)	25000	Overall Dimensions(LxWxHmm)	11980,11200×2500×3080
Curb weight(Kg)	9105	Axles Load(Kg)	6750/6750/11500
Front/Rear wheel Track(mm)	1942/1942,1914/1914,2020/2020 / 1847,1860	Front/Rear Overhang(mm)	1375/3055,1375/2775
Wheel base(mm)	1900+5650,1900+5150	Rear Tread(mm)	2180/2180/2180
Approch/Departure angle(.)	10/18	Drive cab	2 or 3 passengers
Leaf Spring	12/12/10+9,12/3+-/10+9	Max. Speed(km/h)	90
Chassis		CA1251P1K2L7T3EA80
Engine
Model	Manufacture	Displacement(ML)	Power(kw)
CA6DF3-22E3	China Yiqi	6740	188
BF6M1013-24E3	China Yiqi	7146	188
Specifications
I Beam& Chassis	Heavy duty and extra durability designed I beam; Opting for high tensile steel Q345B, welded by automatic Submerged-Arc processes. Top Flange 18mm,width 140mm; Middle Flange 8mm,Height 500mm, Bottom Flange 20mm,width 140mm.
Axle	3 axles (BPW 13ton, FUWA, L1 brand are optional)
Suspension	Heavy duty mechanical suspension
Floor	3mm checker plate
Leaf Spring	13 piece Leaf spring
King Pin	JOST brand 2" Bolt-in King Pin
Landing Gear	JOST brand Two-speed, manual operating, heavy duty landing gear
Wheel Rim	8.25-22.5steel wheel rim
Tire	10.00-20,10.00R20,11.00-20,11.00R20
Ramp	Mechanical ramp with spring
Braking System	WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber; 40L air tanks
Twist Lock	12 nos. of ISO twist lock for 1x20ft, 2x20ft; 1x40ft container, the retractable central locks can be laid down.
Painting	Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
Accessories	One standard tool box

Chengli Special Automobile Co., Ltd, as the "Alibaba Group" in the special vehicle circle, has developed into the biggest professional special vehicle manufacturer of central China starting from scratch since 2004.
LPG tank is one of our most advantageous key products which ranks Top 5 in China, excellent engineers and high-grade production equipment as well as strict quality control system can ensure all the tank work well with 10-20 years use life.

Our main products:
1. Dump Truck / Tipper Truck/Side Tipper/End Tipper
2. Fire Fighting Truck / Fire Truck / Fire Vehicle / Fire Engine
3. Truck with crane / Truck Mounted Crane
4. LPG Tank Truck Trailer/Oil Tank Truck / Fuel Tanker Truck
5. Water Truck / Water Tank Truck / Water Sprinkler Truck
6. Concrete Mixer Truck
7. Van truck / Insulated truck/ Refrigeration truck
8. Fecal suction truck / Sewage Suction Truck,
9. Cement Powder Tank truck/ Bulk Cement Truck
10. High-altitude operation truck,
11. Self-loading Garbage Truck, garbage compactor truck, sealed garbage truck,
12. Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )

Any questions , feel free to contact us:
Catherine Yee
Tel:+18607168573

1. Factory Supply:one of the biggest special purpose truck manufacturers in china,more than 300 kinds of special truck for your choice.

2. OEM Ability: according to your demand, material, dimensions, surface color and the logo are optional for you.

3. Good Quality: with ISO CCC BV certification Solid technology, advanced equipments; reliant quality and flexible modes of operation also have strict quality control system,passed the ISO9001-2008 and the 3C (China Compulsory Certification),our brand is china famous brand with good reputation in the market.

4. Best Service: 24-hour hotline and email during communication.

5. Fast Delivery: 5-10 days after payment(most common products), safe and quick delivery.

Packaging:nude with wax.

Shipping:Ro-Ro/Bulk Ship/Container
