70 Ton Capacity Tipper Semi Trailer/4 Axles Dumper Semi-Trailer

Basic Info Model NO. SWTST7004 Shape Van-type Axle Number 4 Tire Number 16 Self-dumping Self-dumping ABS Anti-lock Braking System as Optonal Material Steel Condition New Hydraulic System Hyva Tire Size 12.00r20 Kingpin Jost 3.5′′ Curb Mass 13.5 Ton Trademark Sinoway Transport Package Nude Specification ISO9001 Origin China HS Code 8716399000 Product Description Customer Question & Answer Ask something for more details (0)

Semi trailer Dimension	11280*2495*3970mm(Outside Dimension)10500*2300*1700(Inside Dimension)
Tare Weight	about 10-15T
Total Volume	37m3 or less than 80tons
Side wall thicknes(mm)	6mm Q235 steel
Bottom plate thickness(mm)	8mm Q235steel
Lifting system	Full set of HYVA Hydraulic Lifting Cylinder
Chassis
Main beam	Height:500mm,upon plate is 16mm,middle plate is 8mm(2-in-1 or 3-in-1 plate),down plate is 18mm;Material is Q345B Steel
Axle	13T/16T,FUWA/BPW/Huajing Brand
Spring leaf	90(w)mm*13(thickness)mm*10Layer or 100mm*12mm*12
King pin	Jost brand 2.0 0r 3.5 inch bolts type or welding type
Landing Gear	JOST brand C200T or China brand 28Tons (Double speed)
Suspension	Mechanical suspension/America Type/Germany Type
Rim	9.00-22.5/8.00-20/8.5-20
Tire	12.00R22.5/315 80R22.5/11.00R20/12.00R20 Various tire brands are available
Pneumatic Braking system	WABCO RE 6relay valve;T30/30+T30 Spring brake chamber,45L air tank
ABS	Optional
Tool box	One piece,1m*0.5m*0.5m(Size can be choose freely)(equipped with 1unit Tire spanner,1 unit gudgeon sleeve and 1unit cranking bar)
Painting	Complete Chassis sand blasting to clean rust,1 coat of anticorrosive prime,2coats of final paint
Shipping term	Transport by bulk cargo carrier or RORO The trailer size can be designed according to your special requirements.
