China Front Reach Stacker Machine Srsc4535gc Price

China front reach stacker machine SRSC4535GC price

Feature

Dynamic Anti-rollover Protection

Uses intelligent control technology to detect equipment's real-time working parameters and automatically adjust the operating status under dangerous conditions to prevent rollover, keeping you safe on the job.

Anti-collision Technology

By using intelligent control to regulate the positions of spreaders and booms, the reach stacker can effectively prevent collision among the spreader, frame and boom. This technology helps eliminate accidents by faulty operation.

Automatic Fire Extinguishing

The pipeline network has an automatic fire extinguisher with strong spray. It is capable of acting as a fire alarm, anti-flaming and fire extinguishing.

Solid Tire Suspension Technology

It features a solid tire flexible damping system to achieve safer operation and lower maintenance cost. Combined with flexible suspension technology, the technology significantly reduces the shocking load while raising operation comfort and prolonging component longevity.

Automatic Braking Technology upon Reversing

By using laser scanning and graphic identification technology, the machine can detect people or obstacles within the driving route with a high degree of precision. The reach stacker then brakes automatically to prevent accidents.

Parameters
Rated power
265/2100kW/rpml
Max.torque
1785/1260Nm/rpm
Emission standard
Stage
Transmission
DANA 15.5HR36000
Drive axle
Kessler D102 PL341
Tire
18.00-33 36PR
Model
SDJ450F
Side shift range
±800mm
Rotation angle
+105/-195
Self weight
7.8t
Application
ISO20'/40'/45' container
Max.lifting height
15100mm
Boom tilt angle
0~58deg
Max.lifting speed (non-load/load)
420/250mm/s
Max.lowering speed (non-load/load)
360/300mm/s
Max.travel speed (non-load/load)
25/18km/h
Gradeability (non-load/load)
38/24%
Hydraulic system work pressure
260bar
Overall weight
76.5t
Max.load
45t
Stacking height
5 (9'6"/8'6")
Overall length
11960mm
Wheel base
6500mm
Overall height
4870mm
Min.ground clearance
350mm
Overall width
6053-12185mm
Front wheel width
3033mm
Rear wheel width
2790mm
Min.turning radius
8800mm
20"container aisle width
12000mm
40"container aisle width
13600mm
Weight motion distance
500mm
