China Front Reach Stacker Machine Srsc4545c2-80 Price

China front reach stacker machine SRSC4545C2-80 price

Feature

Dynamic Anti-rollover Protection

Uses intelligent control technology to detect equipment's real-time working parameters and automatically adjust the operating status under dangerous conditions to prevent rollover, keeping you safe on the job.

Anti-collision Technology

By using intelligent control to regulate the positions of spreaders and booms, the reach stacker can effectively prevent collision among the spreader, frame and boom. This technology helps eliminate accidents by faulty operation.

Automatic Fire Extinguishing

The pipeline network has an automatic fire extinguisher with strong spray. It is capable of acting as a fire alarm, anti-flaming and fire extinguishing.

Solid Tire Suspension Technology

It features a solid tire flexible damping system to achieve safer operation and lower maintenance cost. Combined with flexible suspension technology, the technology significantly reduces the shocking load while raising operation comfort and prolonging component longevity.

Automatic Braking Technology upon Reversing

By using laser scanning and graphic identification technology, the machine can detect people or obstacles within the driving route with a high degree of precision. The reach stacker then brakes automatically to prevent accidents.

Reliable Structure Design

Featuring a joint Chinese-German design, the machine underwent a full-digit prototype design system. During development, the design underwent finite element analysis (FEA) and dynamics simulation analysis, as well as strict endurance and vibration tests.

Reliable Power System

Using world-famous engines like Volvo and Cummins, which combine advanced power matching and control technology, SANY equipment is optimized for dynamic performance. The engine and gearbox are protected, significantly prolonging their longevity.

Parameters
Rated power
250/2100kW/rpm
Max.torque
1674/1400Nm/rpm
Emission standard
Tier
Transmission
Dana 15.5HR36000
Drive axle
Kessler D106
Tire
21.00-35 36PR
Spreader
Model
SDJ450F
Side shift range
±800mm
Rotation angle
+105°/-195°
Self weight
7.8t
Application
IS0 20'/40'/45' containers
Boom
Max.lifting height
13600mm
Boom tilt angle
0°~50°
Performance
Max.lifting speed (non-load/load)
400/220mm/s
Max.lowering speed (non-load/load)
360/280mm/s
Max.travel speed (non-load/load)
20/15km/h
Gradeability (non-load/load)
26/17%
Hydraulic system work pressure
260 bar
Overall weight
96.5t
Max.load
45 t
Stacking height
5(8'6")
Overall length
13270mm
Wheel base
8000 mm
Overall height
5230mm
Min.ground clearance
420mm
Overall width
6053-12185mm
Front wheel width
3060mm
Rear wheel width
3120mm
Min.turning radius
10600mm
20"container aisle width
14500mm
40"container aisle width
15200mm
