China Heli Forklift Truck Price with Cpd18

FOB Price: USD 25000.50 /Unit
Min.Order: 1 Unit
Supply Ability: 81 Unit
Delivery time： 17 days

Product Description

China heli forklift truck price with CPD18

Model		CPD15	CPD18
Configuration No.		CJ1/CJ2	CJ1/CJ2
Load capacity	kg	1500	1750
Load center	mm	500	500
Standard mast lifting height	mm	3000	3000
Free hoisting height	mm	155	155
Overall height (upper frame protection)	mm	2160	2160
Full length (without pallet fork)	mm	2130	2160
Full width (before/after)	mm	1070	1070
Wheelbase	mm	1370	1370
The minimum ground clearance (the door)	mm	110	110
The minimum turning radius (outer)	mm	1930	1960
Least square channel width (1200 * 1200 mm tray, 20 mm gap)	mm	3760	3790
Pallet fork length * width * thickness	mm	35100920	35100920
The door frame Angle(before/after)	deg.	6/12	6/12
Tire type(before/after)		Pneumatic tyres	Pneumatic tyres
Maximum speed (full/empty)	km/h	14/15	14/15
Maximum gradeability (full/empty)	%	17/25	15/23
Hoisting speed (full/empty)	mm/s	270/450	280/530
Battery capacity	V/Ah	48/550	48/550
Control mode (driving, pump)		Ac/dc control	Ac/dc control
The total battery (reservation)	kg	3000	3250
*Ac lifting speed (full/empty)	mm/s	340/490	330/490
*Control mode (driving, pump)		Exchange control	Exchange control

-------------------
Amanda
Mobile: +8618721040484
https://www.facebook.com/amanda.huang.44
amanda[at]newindu[dot]com
Http://www.evangelchina.com/
Newindu E-Commerce(Shanghai) Co., Ltd&Evangelchina Construction Machinery Solutions
Address: Suite 1305, Fortune Times Tower, No. 1438 North Shanxi Road

Product Images

China Heli Forklift Truck Price with Cpd18 Images 1
