Good Condition Horizontal Directional Drill Machine Xz500 Price

Good condition Horizontal directional drill machine XZ500 price

Feature
• Hydraulic system: Adopt many advanced control techniques, such as closed energy-efficient circuit, hydraulic pilot control, electrohydraulic proportion control, etc.
• Rotation: It is driven by both the motor and the reducer with two gears to control the speed.
• Feed/retract: Pull or push with the gear rack. There are two gears to control the speed, which has high working efficiency.
• Cab: The single cab with air conditioning makes the operation easy and comfortable.
• Engine: The turbocharging engine has large power reserve, guaranteeing the drilling power demand.
•Drill stand: The high-intensity drill stand is fit for the 4.5m drill rod. The drill stand can slide, which facilitates the angle adjustment.
• Drill rod holder: The movable holder and Truck Mounted Crane make the drill installment and dismantlement efficient and labor-saving.
• Track: The self-propelled steel tracks move and turn conveniently. It is driven by wire, and the speed can be shifted between high speed and low speed.
• Monitoring and protection: The engine, hydraulic pressure, filtration monitoring and alarming can effectively protect the machine safety.
Parameters

Feed/retract	Type		Two-motor driving gear rack
	Max. retract/feed force	kN	500/500
	Drill unit running speed	m/min	0~20
Rotation	Type	Motor+reducer driving gear transmission
	Max. drill unit torque	N.m	18000
	Drill unit rotate speed	r/min	0~108
Drill rod	Diameter	mm	φ89
	Length(single)	m	4.5
Drill stand	Type		Sliding box drill stand
	Drilling angle	°	10~20
Truck mounted crane	Type	Full rotary straight boom retractable crane
	Max. hoisting weight	t	2
Travel drive	Type		Steel track self-propelled
	Travel speed	km/h	1.8
	Flow rate	L/min	600
Dimensions		mm	9280×2755×3000
Weight		t	18
