Sany Sr360RC10 Rotary Drilling Rig

Sany Sr360RC10 Rotary Drilling Rig

SR360RC10 rotary drilling rig is suitable for large diameter hard rock drilling.
High drilling capacity
14-19m friction Kelly, 14-19m interlocking Kelly made of high strength steel tubes are available; Maximum output torque reaches 360kN.m, the maximum pile depth is 106m down, maximum pile diameter is 2500mm, 3000mm after remove the lower mast.
Isuzu engine with rated power of 300kW@1800rpm, six gears control provides strong power to the machine, improving the drilling capacity.
Main winch with dual reducer and dual motor delivers faster line speed of 75m/min, bigger lifting power with 360kN line pull.
Safe and reliable
The 5th generation rotary drive adopts multi-gear control, self-adaptive techniques, and double buffering system which can increase drilling efficiency and safety.
Anti-shock heavy duty hydraulic system tailor-made with renowned brands and heavy extended chassis with low gravity ensure efficient, safe and stable operation.
Advanced welding robots, CNC automatic cutting machines ensure high precision and quality of the core components.
Easy to operate&maintain
Auto center lubrication system is equipped to facilitate the secure and efficient lubrication of the drilling rig.
Optimized layout, larger spaces for pumps and valves is for easy maintenance during work.
Spacious cab with panorama sunroof, SANY-ADMS intelligent operation system designed to give the operator a comfortable environment and wide visibility.

Main performances
Overall height
27,314 mm
Operating weight
114 t
Max. pile diameter
2,500 mm
Max. pile depth (friction bar)
106 m
Max. pile depth (interlocking bar)
69 m
Rotary drive
Max. output torque
360 kN m
Rotation speed
5~25 rpm
Crowd system
Crowd force
290 kN
Line pull
250 kN
Stroke
6,000 mm
Winches
Main winch - line pull
360 kN
Main winch - rope diameter
36 mm
Main winch - max. line speed
75 m/min
Auxiliary winch - line pull
90 kN
Auxiliary winch - rope diameter
20 mm
Auxiliary winch - max. line speed
70 m/min
Mast inclination
Forward/Backward
4°/90°
Lateral
±4°
Main parameters
Chassis length
7,850 mm
Extended width
4,840 mm
Track shoe width
800 mm
Swing radius (backside)
4,705 mm
Transport width
3,532 mm
Transport height
3,744 mm
base engine
ISUZU AH- 6WG1X
Engine power
300/1,800 kW/rpm
Emission standard
COM3/R96
Engine displacement
15.68 L
