/Widely Used Sany Small Concrete Mixing Pump
- Price can be negotiated
- 1 Unit
- 47 Unit
- 25 days
Product Description
Product Feature
Sany HBT6013C-5S trailer pump has maximum output of 65 cubic meter per hour, equipped with self-diagnosis technology monitoring the pump status at any time as well as diagnosing more than 50 faults in real time. The 65 cubic meter trailer pump is capable of reducing the troubles shooting time by 70%, granting you both time and peace of mind.
Main Parameters
about Us
Sany HBT6013C-5S trailer pump has maximum output of 65 cubic meter per hour, equipped with self-diagnosis technology monitoring the pump status at any time as well as diagnosing more than 50 faults in real time. The 65 cubic meter trailer pump is capable of reducing the troubles shooting time by 70%, granting you both time and peace of mind.
Main Parameters
| Model | HBT6013C-5S |
| Max. delivery pressure Low/High pressure | 8/13 Mpa |
| Max. concrete output Low/High pressure | 65/40 m3/h |
| Rated power | 114 kw |
| Delivery cylinder Bore*Stroke | ∅200*1400 mm |
| Hopper capacity*Feeding height | 0.7*1420 m3/mm |
| Dimension(L*W*H) | 6730*2100*2600 mm |
| Gross weight | 6000 kg |
| Max. aggregate sizeΦ150mm delivery pipe | 50 mm |
| Max. aggregate sizeΦ125mm delivery pipe | 40 mm |
| Type | S-Valve |
| Slump of concrete | 100~230 mm |
