Lutong Ltc214 14 Ton Hydraulic Double Drum Road Roller

LUTONG famous double drum road roller LTC214 -14ton

LTC214 Hydraulic vibratory rollers are manufactured according to international advanced technology and by use of imported components from abroad. The machine is a double drum tandem vibratory roller,It is Primarily used for the ompation of road bituminous course,sand gravel mixtures and RCC material,Being a universal compaction equipment for highway,municipal road,park area and industry ground etc.

Main Features
Full hydraulic two wheel drive and vibration.
Double frequency double viration system.
Hydrostatic center articulated steering,Optional unique crab agency.
Cabin with air conditooner,comfortable and spacious,the flexible steering seat facilicates the operation.
The driver's cabin can be turned on one side as a whole, to facilitate maintenace.
Fork-type frame,good hold-down property.
Hydraulic pump and vibrating motors are of the products made by American manufacturer SAUER or German manufacturer REXROTH.


We also have 8ton, 10ton, 12ton double steel drum road roller!
Welcome to inquiry!

Main technical parameters

MODLE		LTC214 LTC212	LTC210 LTC208
Operating mass	kg	14000/12000	10000/8000
Front axle load	kg	7000/6000	5000/4000
Rear axle load	kg	7000/6000	5000/4000
Static linear load	N/cm	333/286	238/231
Form of frame		Fork-type()	Fork-type()
Water tank capacity	L	2×600	2×400
Fuel tank capacity	L	154	80
Hydraulic tank capacity	L	65	65
Vibration frequency	mm
High ampl.		0.8	0.67
Low ampl.		0.4	0.34
Vibration frequency	Hz
High ampl.		40	45
Low ampl.		46	50
Centrifugal force	kN
High ampl.		160×2	90×2
Low ampl.		90×2	69×2
Travel speed	km/h	0-12	0-10
Turning radius	mm	7000	6000
Grade ability	%	40	40
Steering angle	°	±30	±30
Drum diameter	mm	1350	1150
Drum width	mm	2100	1730
Transverse swing angle of the vibrating wheel	°	±8	±8
Type of water spray	mm	Pressure	Pressure
Wheelbase	mm	3717	3217
Overall length	mm	5060	4558
Overall width	mm	2250	1840
Overall height	mm	3300	2674
Ground clearance	mm	324	258
Diesel model		6BT5.9	4BT3.9
Diesel power	kw	110	75
Dieselspeed	r/min	2300	2400
