Small Cheap Earthmoving Machinery Crawler Excavator Sy55c Price

Small cheap earthmoving crawler Excavator machinery SY55C price

Feature

SY50 small excavator (5 ton excavator)features wide adaptability, high fuel efficiency, low environmental impact and easy maintenance.

Advanced Engine and Hydraulic System

Super powerful engine combines with the new electrical positive flow hydro-system, making the 5 ton excavator highly efficient and well adapted to different operating conditions.

Durable and Reliable

With reinforced working device and high-strength swing plant, construction components' life span are improved 30%.

High Efficiency

Accurate and adjustable flow control makes the excavator worked faster and more efficiently.

Parameters

Engine
Engine model
4TNV88C-PSY
Rated power
29.1/2400 kW/rpm
Max.torque
133.3~144.9/(1560±100) N·m/rpm
Displacement
2.19 L
Emission standard
Tier 4 Final
Operation Range
Operating weight
5400 kg
Max. digging height
5435 mm
Max. dumping height
3795 mm
Max. digging depth
3430 mm
Max. vertical digging depth
2470 mm
Max. digging reach
5880 mm
Min. swing radius
2520 mm
Height at min.swing radius
4145 mm
Max.ground clearance of blade up
420 mm
Max.depth of blade down
405 mm
Dimensions
Transport length
5380 mm
Transport width
1960 mm
Transport height
2620 mm
Upper width
1760 mm
Blade height
340 mm
Tail swing radius
980 mm
Min. ground clearance
315 mm
Counterweight ground clearance
660 mm
Undercarriage/Working Device
Std. track shoe width
400 mm
Track shoes(per side)
40
Carrier roller(per side)
1
Lower roller(per side)
4
Track gauge
1560 mm
Roller gauge
1970 mm
Boom length
2700 mm
Arm length
1500 mm
Performance
Travel speed
2.4/4.1 km/h
Swing speed
10 rpm
Gradeability
30°
Ground pressure
32 kPa
Tractive force
40.7 kN
Bucket digging force
31.5 kN
Arm digging force
21.2 kN
Service Refill Capacities
Fuel tank
78 L
Hydraulic tank
52 L
Engine oil
7.4 L
Engine coolant
5.7 L
Hydraulic System
Boom cylinder bore x stroke
90×640 mm
Arm cylinder bore x stroke
80×690 mm
Bucket cylinder bore x stroke
70×590 mm
Blade cylinder bore x stroke
95×180 mm
