Low Price Front Crawler Excavator Machine Sy60c in India

Low price front crawler Excavator Machine SY60C in India

Feature

•Tier4 final compliant engine satisfies the emission regulations of North America.

•The SLSS hydraulic system developed by an international team ensures precise operation and energy conservation;

•Extra reinforcements in the boom, arm, swing platform and undercarriage increase stability and service life.

•Easily accessible service points and a detachable radiator screen are among the features that make scheduled maintenance more convenient.

Parameters

Engine
Engine model
KUBOTA V2607
Rated power
45/2200 kW/rpm
Max.torque
225/1500 N·m/rpm
Displacement
2.615 L
Emission standard
Tier 4final
Operation Range
Operating weight
5780 kg
Max. digging height
5705 mm
Max. dumping height
3945 mm
Max. digging depth
3830 mm
Max. vertical digging depth
3085 mm
Max. digging reach
6110 mm
Min. swing radius
2555 mm
Height at min.swing radius
4495 mm
Max.ground clearance of blade up
385 mm
Max.depth of blade down
380 mm
Dimensions
Transport length
5925 mm
Transport width
2005 mm
Transport height
2830 mm
Upper width
1860 mm
Blade height
340 mm
Tail swing radius
1640 mm
Min. ground clearance
330 mm
Counterweight ground clearance
705 mm
Undercarriage/Working Device
Std. track shoe width
400 mm
Bucket capacity
0.21 m³
Carrier roller(per side)
1
Lower roller(per side)
5
Track gauge
1600 mm
Roller gauge
2045 mm
Boom length
3000 mm
Arm length
1700 mm
Performance
Travel speed
3.73/2.40 km/h
Swing speed
9.6 rpm
Gradeability
35°
Ground pressure
32.75 kPa
Tractive force
47.2 kN
Bucket digging force
45 kN
Arm digging force
33 kN
Service Refill Capacities
Fuel tank
130 L
Hydraulic tank
85 L
Engine oil
9.6 L
Engine coolant
5.6 L
Hydraulic System
Boom cylinder bore x stroke
115×710 mm
Arm cylinder bore x stroke
90×815 mm
Bucket cylinder bore x stroke
85×605 mm
Blade cylinder bore x stroke
120×150 mm
