Lutong 10- 20ton Hydraulic Vibratory Road Roller with Cummins Engine

Lutong Road Roller with Cummins Engine

Ltd220H Ltd218H Ltd216H Ltd214H Ltd212H Ltd210H Hydraulic vibratory roller is manufactured according to the international advanced technology and by use of imported components from abroad. The machine is super heavy-dutyvibratory roller, possesses a great working mass and strong centrifugal force. It is the best compaction equipment of high quality and high effect in the large-scale mechanized construction. This machine is suitable for non-cohesive materials, such as graves, macadam, macadam-aggregate mixtures and sandy soil etc. Also it can be a good effect compaction in cohesive material, There fore the machine an ideal equipment for expressway. Mining road, embankment, seaport and industrial sites.

Main Features
Power System: CUMMINS B-series extra-pressure diesel engine, huge power man coeffciency, complicable for the operating condition above 4000 meters altitude.
Total hydraulic pressure, total drive, frequency and radiation conversion, articulated direction change, two stepless speed changes, advanced technology; Blocking the oil supply to brake the vehicle, safe and reliable.
Streamline outline, circular windshield glass and curvy hood form a unique style.
Hydraulic pump and vibrating motors are of the 90 series made by the American manufacturer SAUER.
Equipped with padfoot or removal padfoot as option.

Main Technical Parameters
		LTD220H	LTD218H	LTD216H
Operating mass	Kg	20000	18000	16000
Static linear load	N/cm	600	540	457
Vibration ampiltude	mm	2.0/1.0	1.0	2.0/1.0
Vibration frequency	Hz	28	35	(28/35)
Centrifugal force	kN	(410/300)	(395/290)	(320/260)
Travel speed	km/h	11	11	11
Grade ability	%	35	35	35
Turning speed	mm	7500	7500	7500
Overall dimension	mm	5820x2340x3050	5820x2340x3050	5820x2278x3050
Vibration round width	mm	2100	2100	2100
Wheelbase	mm	3160	3160	3160
Ground clearance	mm	472	472	472
Diesel power	kW	132	132	110
Diesel model		Cummins6BTA5.9	Cummins6BTA5.9	Cummins6BT5.9

Main Technical Parameters
		LTD214H	LTD212H	LTD210H
Operating mass	Kg	14000	12000	10000
Static linear load	N/cm	400	340	285
Vibration ampiltude	mm	(1.8/0.9)	1.8	0.9
Vibration frequency	Hz	(29/35)	29	35
Centrifugal force	kN	(290/180)	(260/1600)	(240/120)
Travel speed	km/h	12	12	12
Grade ability	%	35	35	35
Turning speed	mm	7000	7000	6500
Overall dimension	mm	5820x2278x3050	5820x2278x3050	5820x2278x3050
Vibration round width	mm	2100	2100	2100
Wheelbase	mm	3160	3160	3160
Ground clearance	mm	472	472	472
Diesel power	kW	110	110	110
Diesel model		Cummins6BT5.9	Cummins4BT3.9	Cummins4BT3.9

-------------------
