Full Hydraulic Vibratory Roller 12 Ton (LTC212)

LTC212 Hydraulic vibratory rollers are manufactured according to international advanced technology and by use of imported components from abroad. The machine is a double drum tandem vibratory roller. It is Primarily used for the compaction of road bituminous course, sand gravel mixtures and RCC material, Being a universal compaction equipment for highway, municipal road, park area and industry ground etc.

Main Features:
1. LTC212 Hydraulic double drum vibratory road roller. Full hydraulic two wheel drive and vibration.
2. Double frequency double vibration system.
3. Hydrostatic center articulated steering, patented crab mechanism.
4. Cabin with air conditooner, comfortable and spacious, the flexible steering seat facilitates the operation.
5. The driver's cabin can be turned on one side as a whole, to facilitate maintenance.
6. Hydraulic pump and vibrating motors are of the products made by American manufacturer SAUER of German manufacturers REXROTH.

Model		LTC212
Operating mass	kg	12000
Font axle load	kg	6000
Rear axle load	kg	6000
Static linear load	N/cm	286
Crabwise movement distance	mm	± 170
Water tank capacity	L	2x600
Fuel tank capacity	L	154
Hydraulic tank capacity	L	65
Vibration frequency	mm
High ampl	mm	0.8
Low ampl	mm	0.4
Vibration frequency	Hz
High ampl	Hz	40
Low ampl	Hz	46
Centrifugal force	kN
High ampl	kN	160x2
Low ampl	kN	90x2
Travel speed	km/h	0-12
Turning radius	mm	7000
Grade ability	%	40
Steering angle	.	± 35
Drum diameter	mm	1350
Drum width	mm	2100
Drum rim thickness	mm	20
Transverse swing angle of the vibrating wheel	.	± 8
Type of water spray		pressure
Wheel base	mm	3717
Overall length	mm	5062
Overall width	mm	2250
Overall height	mm	3000
Ground clearance	mm	324
Diesel model		6BT5.9
Diesel power	kW	110

-------------------
