Low price Single Drum Road Roller Machine XS122
Feature
XS122 is a medium-sized hydraulic vibratory compactor developed on the basis of XS120 with better performance and appearance. Representing hydraulic vibratory compactors, the compacting performance, driving performance, operating performance, reliability, and maintenance performance represent the highest level of domestic compactors.
Comfortable operating environment
Full hydraulic drive makes operations easy and convenient. The instrument panel accords with the ergonomics, equipped with suspended seat and car radio, making the driving more comfortable.
The air conditioning supplies comfortable operating environment.
Remarkable compacting performance
The welded convex block drum and fabricated expand the application range, realizing "one machine, two purposes".
Outstanding powertrain
Adopt the imported water-cooled turbo-charged engine, features reliable performance, large power reserve, low oil consumption, low noise, meeting the standard of European II.
Adopt imported heavy-duty drive axles with NO-SPIN Differential. The drive wheels adopt wide base tyres which have large ground connection area, improving the driving performance, and ensuring good trafficability in any case.
Hydraulic drive system: adopt the closed anti-slip hydraulic drive system composed by imported heavy-load variable pump and motor, ensuring the good driving performance and high gradeability.
Reliable Electrical System
The electrical system adopts imported water-proof, dust-proof, vibration-resistant electric connectors for increased reliability.
imported maintenance-free battery has high start-up current and good adaptability.
Parameters
| Type | Unit | Specifications |
|---|---|---|
| Operating weight | kg | 12000 |
| Weight on front drum | kg | 6700 |
| Static linear load | N/cm | 308 |
| Speed range | km/h | 0~10.4 |
| Theoretical gradeability | % | 45 |
| Min. external turning radius | mm | 6800 |
| Steering angle | ° | ±30 |
| Oscillating angle | ° | ±10 |
| Vibration frequency(L/H) | Hz | 30/35 |
| Nominal amplitude(H/L) | mm | 1.80/0.9 |
| Excitation force(H/L) | kN | 290/180 |
| Drum diameter | mm | 1523 |
| Drum width | mm | 2130 |
| Engine model | 4B3.9 | |
| Type | Water cooled, turbo-charged,air-air intercooling | |
| Rated power @2200r/min | kW | 93 |
