/Road Construction Machinery Liugong Motor Graders Machine Price Clg414
- USD 30000.50 /Unit
- 1 Unit
- 10 Unit
- 14 days
Product Description
Road construction machinery Liugong motor graders machine price CLG414
Feature
Dustproof, sound reducing, shock absorbing and anti-UV cabin.
Comfortable adjustable suspension seating.
Air Conditioning optional.
Full range of visibility.
Parameters
| Engine | DCEC 6BTAA5.9-C160 | |
| Rated Power | (kW) | 118 (160)@2200 |
| Blade Width | mm(inches) | 3660(144) |
| Maximum Speed | km/h (mph) | 41 (25.5) |
| Draw Bar Pull | (kN) | 65 |
| Operating Weight | kg(Lb) | 12800(28219) |
| ENGINE | ||
| Tier | II | |
| Make | ||
| Gross Power | kW(Hp)@rpm | 118 (160)@2200 |
| Net Power | kW(Hp)@rpm | 109(148)@2200 |
| Peak Torque | 690N.m/1300rpm | |
| Torque Rise % | 34% | |
| Number of Cylinders | 6 | |
| Aspiration | turbo air-to-air aftercooled | |
| TRANSMISSION | ||
| Transmission Type | power shift | |
| Transmission Configuration | 6f/3r | |
| Torque Converter | three-member single turbine | |
| Maximum Travel Speed, fwd | (km/h) | 41 |
| Maximum Travel Speed, rev | (km/h) | 29 |
| Number of Speeds, fwd | 6 | |
| Number of Speeds, rev | 3 | |
| AXLES | ||
| Front Axle Make | LiuGong Weld axle | |
| Rear Axle Make | Meritor | |
| Differential Type | NO-SPIN limited slip standard | |
| Final Drive Type | chain drive | |
| Axle Oscillation | ±15º | |
| Front Axle Type | all welded steel frame | |
| Front Axle, Wheel Lean Angle | ±17º | |
| STEERING | ||
| Steering Configuration | oad sensor steering gear | |
| Steering Relief Pressure | (Mpa) | 17 |
| Minimum Turning Radius | (inches) | 7200(283) |
| Steering Angle | ±45º | |
| frame Articulation Angle | ±20º | |
| BRAKES | ||
| Service Brake Type | (Dry) shoe | |
| Service Brake Location | rear axle only | |
| Service Brake Actuation | hydraumatic | |
| TIRES | ||
| Tire Size | 13.00-24 | |
| HYDRAULIC SYSTEM | ||
| Main Pump Type | gear | |
| Main Relief Pressure | (Mpa) | 18 |
| Pilot Pump Flow | L(Gal)/min | 119(31) |
| WORKING CAPACITIES | ||
| Maximum Draw Pull | (kN) | 65 |
| Cutting Pressure | kg(Lb) | 5500(12125) |
| TANDEM DRIVE PERFORMANCE | ||
| Height | mm(inches) | 580(23) |
| Width | mm(inches) | 210(8) |
| Thickness, inner wall / outer wall | mm(inches) | 20/20(0.8/(0.8) |
| Center Distance | mm(inches) | 1540(61) |
| Oscillating Angle | ±15º | |
| MOLDBOARD PERFORMANCE | ||
| Bank Cut Angle | 40~70 | |
| Moldboard Lift Above Ground | mm(inches) | 460(18) |
| Moldboard Side Shift, right / left | mm(inches) | 650/520(26/20) |
| Maximum Sloping Angle | 90º | |
| Cutting Depth | mm(inches) | 600(24) |
| Circle Rotation | 360º | |
| Circle Diameter | mm(inches) | 1265(50) |
| Circle Thickness | mm(inches) | 120(5) |
| DIMENSIONS | ||
| Wheelbase | mm(inches) | 5900(232) |
| Overall Length | mm(inches) | 8340(328) |
| Overall Height with Cab | 3370(133) | |
| Overall Width | mm(inches) | 2465(97) |
| Clearance under Front Axle | mm(inches) | 570(22) |
| Moldboard Standard Length | mm(inches) | 3660(144) |
| Moldboard Standard Thickness | mm(inches) | 19(0.7) |
| Moldboard Standard Height | mm(inches) | 610(24) |
| OPERATING WEIGHTS | ||
| Operating Weight | kg(Lb) | 12800(28219) |
| On Front Wheels | kg(Lb) | 3400(7496) |
| On Rear Wheels | kg(Lb) | 9400(20723) |
| SERVICE CAPACITIES | ||
| Fuel Tank | L(Gal) | 250(66) |
| Engine Oil | L(Gal) | 17(4) |
| Cooling System | L(Gal) | 40(11) |
| Hydraulic Reservoir | L(Gal) | 100(26) |
| Transmission And Torque Converter | L(Gal) | 45(12) |
| Tandems, Each | L(Gal) | 23(6) |
