China Hot Brand XCMG New Small Excavator Machine Xe18

China hot brand xcmg new small Excavator machine XE18

Feature

XE series(XE18,XE40,XE60,XE80) of crawler hydraulic excavator is the excavating machinery product manufactured by recently, with featured in comfortable operation, more powerful digging force, wide vision, escellent control performance, smooth and efficient operation etc., which makes them suitably applied to bi used tor various working conditions in re-maintaining road surfaces, laying pipelines, digging base layer of soil, gardening cultivation , and trimming river silt etc.

1.Powerful and economical power system

The original imported enging is environmental and economical, with featured in super power , stable performance, lower fuel consumption and efficient performance, low noise, low vibration, low exhaust and good performance of low temperature start.The imported compound radiator has excellent structure with advantages of convenient cleaning, small flow resistance and efficient cooling, and remarkable heat balance which takes excellent performance when the machine works under super-loading and consisting operating. With air-filtering system of level 3for air-filling system and oilfilling system, it ensures the filling oil and air clean, which makes the machine more suitable for atrocious working condition.

2.Reliable hydraulic system

The variable control system, adopted as a popular configuration in the market, which can change the system pressure and distribute the flow reasonably according to loading variation in order to ensure the machine holding the strongest digging ability and optimized operational combination, so as to make the engine working sufficiently.

The whole set of hydraulic system components, including:hydraulic pumps, multi-way valves, slewing motor, driving motor and pilot control units, are internationally procured parts, which ensures easy operation control, their reliable performane, stable maneuverability.

Parameters

Model			XE18
Bucket capacity		m3	0.044
Standard bucket width		mm	475
Operation weight		kg	1780
Dimension(in transportation)	Overall length	mm	3760
	Overall width	mm	1300
	Overall height	mm	2405
	Min. clearance	mm	180
Engine	Model		3TNV82A
	Total displacement	L	1.33
	Rated output power	KW/rpm	16.5/2200
Digging performance	Max. digging height	mm	3,653
	Max. dumping height	mm	2,515
	Max. digging depth	mm	2,285
	Max. vertical digging depth	mm	2,067
	Max. digging radius	mm	3,915
	Boom deflection angle	°	70/50°
	Min. slew radius	mm	1674
	Min. rear slew radius	mm	1190
	Bucket digging force	kn	13.9
Track type			Rubber
Track width		mm	230
Travel System	Track length	mm	1578
	Wheel base	mm	1217
	Track gauge	mm	1070
	Travel speed (Gear I/II)	km/h	4.4/2.4
	Gradeability	%	58
Slew speed		rpm	11
Bulldozing plate	Bulldozing plate width	mm	1300
	Bulldozing plate height	mm	235
	Lifting distance	mm	236/204
Hydraulic pump type			Variable pump×2 +gear pump×1
Slew motor type			Piston hydraulic motor
Travel motor type			Piston hydraulic motor
Fuel tank capacity		L	20
Hydraulic oil tank capacity		L	29
