Good Condition New Mini Excavator Price Xe15 for Sale

Good condition new mini Excavator price XE15 for sale

Feature

The complete machine is small and exquisite in size and turning radius, mainly suitable for landscaping, urban construction, pipeline laying and other working conditions. featuring low noise and excellent economical efficiency. The complete machine boasts outstanding inching performance and small impact by virtue of the perfect matching of the engine and the hydraulic components. Its cab uses silicone oil shock absorption with a new suspension seat provided, able to give the operator a comfortable working environment. The hydraulic main valve and key hydraulic pipelines and daily maintenance points are arranged in the full-open front and rear hoods, which can further facilitate daily maintenance. The complete machine is configured with standard high-power air-conditioning system, standby power, magazine bags and storage boxes, etc. in accordance with a humanized design. The optional rubber tracks, steel tracks, quartering hammers, quick changers and other auxiliary equipment have significantly improved its capacity for dealing with all kinds of working conditions.

Parameters

Operating weight		kg	1640
Standard bucket capacity		m³	0.044
Engine	Engine Model	/	3TNV82A
	Direct injection	/	√
	Four strokes	/	√
	Water cooling	/	√
	Turbo charged	/	×
	Air to air intercooler	/	×
	No. of cylinders	/	3
	Rated power/speed	kw/rpm	16.5/2200
	Max. torque/speed	N.m	86.5/1320
	Displacement	L	1.33
The main performance	Travel speed	km/h	4.4/2.4
	Swing speed	r/min	11
	Max. gradeability	/	30°
	Ground pressure	kPa	23.8
	Max.Bucket digging force	kN	13.9
	Max.arm crowd force	kN	8.8
	Main pump	/	Japan nachi
Hydraulic system	Rate flow of main pump	L/min	2×19.8+14.1
	Max pressure of prime relief valve	MPa	24
	Max pressure of travel system	MPa	21
	Max pressure of swing system	MPa	18
	Max pressure of pilot system	MPa	3.3
	Fuel tank capacity	L	20
Oil capacity	Hydraulic tank capacity	L	29
	Engine lubrication	L	5.5
	A Overall length	mm	3760
Overall dimensions	BOverall width	mm	1080
	C Overall height	mm	2400
	D Overall width of upperstructure	mm	1080
	E Track length	mm	1578
	F Overall width of undercarriage	mm	1080
	G crawer width	mm	230
	H Dozer black(width/height)	mm	1080×225
	I Tumbler distance	mm	1217
	J Crawer gauge	mm	850
	K Clearance under counter weight	mm	472
	L Ground clearance	mm	180
	M Min.tail swing radius	mm	1190
	A Max. digging height	mm	3615
Working range	B Max. dumping height	mm	2480
	C Max. digging depth	mm	2320
	E Max. vertical wall digging depth	mm	1520
	F Max. digging reach	mm	3915
	G Min. swing radius	mm	1675
	H Max.dozer lifting height	mm	220
	I Max.dozer cutting depth	mm	240
	Angle of arm deflection	Degree	70/50
