China top sale front crawler Excavator Machinery SY365C

Feature

Sany SY365C 36.5 tonlarge excavatoradopts customized engine, fast speed, high fuel efficiency and comfortable operating environment, an exceptional choice for infrastructure construction.

High Efficiency & Low Consumption

Isuzu Engine Customized for SANY

With a dual-pump, dual-circuit constant power control system, the engine can fully develop its power. The perfect combination of this two realizes the heavy-duty mode with large workload, the standard-mode with auto-adjusted engine speed and light-duty mode, high efficiency and low fuel consumption, while optimizing the combustion.

Faster Digging Speed and Lower Energy Loss

A quick circuit is added to the arm oil cylinder circuit. The hydraulic oil in arm cylinder rod end does not return the tank but goes directly to the cylinder head end. The arm speed is increased as a result. The fuel consumption is lower under this condition.

Auto Deceleration System

Auto deceleration or acceleration of SY365C 35.2 tonexcavatorreduces fuel consumption by 5-10%. When an operation stops for 3 seconds, the engine speed drops automatically to idle level and maintains the idling state. When the operation is resumed, the engine speed will increase to the set rmp within 0.1 second.

Comfortable & Safe Cab

Innovative Large Cab

The height of seat, the inclination of backrest, the height of armrest, the seat position and headrest can be adjusted as desired.

Parameters

Engine
Engine model
Cummins QSL9
Rated power
205/1900 kW/rpm
Max. torque
1213/1500 N·m/rpm
Displacement
9 L
Emission standard
Tier 4 Final / EU Stage IV
Operation Range
Operating weight
36200 kg
Max. digging height
10135 mm
Max. digging depth
7330 mm
Max. dumping height
7180 mm
Max. vertical digging depth
5850 mm
Max. digging reach
11070 mm
Min. swing radius
3800 mm
Height at min.swing radius
7940 mm
Dimensions
Transport length
9728 mm
Transport width
3080 mm
Transport height
3675 mm
Upper width
3145 mm
Tail swing radius
3330 mm
Min. ground clearance
550 mm
Undercarriage/Working Device
Std. track shoe width
600 mm
Bucket capacity
1.5 m³
Track shoes(per side)
49
Upper rollers
2
Lower rollers
9
Track gauge
2590 mm
Track length
5065 mm
Boom length
6500 mm
Arm length
3200 mm
Performance
Travel speed
3.2/5.4 km/h
Swing speed
9.5 rpm
Gradeability
35°
Ground pressure
56.2 kPa
Tractive force
274 kN
Bucket digging force
200 kN
Arm digging force
169 kN
Service Refill Capacities
Fuel tank
540 L
Hyd tank
340 L
Engine oil
21.5 L
Engine coolant
20 L
Hydraulic System
Boom cylinder bore x stroke
140×1480 mm
Arm cylinder bore x stroke
170×1685 mm
Bucket cylinder bore x stroke
140×1285 mm
