Large China Front Crawler Excavator Machinery Sy215c Price

Large china front crawler Excavator machinery SY215C price

Feature

SY215C 23.4 tonexcavatorfeatures customized engine, strengthened components, high operating efficiency, low fuel consumption, easy maintenance and comfort cabin.

High Efficiency & Low Consumption

Working Efficiency Up by 8%

Innovative controller with faster consumption and more accuracy reduces the response time of hydraulic elements, lowers the internal power loss of the system and increases the operating output power.

Fuel Consumption Down by 10%

The positive flow controlled by hydraulic system considerably reduces fuel consumption. Advanced computer dynamic control technology provides a real-time match between engine power and main pump power. Four power modes maximize fuel economy.

Digging Force Up by 9.5%

Enhanced work equipment can bear high pressure of quality hydraulic elements and circuits, and strengthen the digging force.

High Reliability

Powerful Customized Machine

The Mitsubishi engine with rate power of122/2300 kW/rpm, 6-cylinder, 4-stroke direct-injection turbocharger, and 5.86L displacement is customized for SANY excavators, meeting your expectation on engine stability.

Parameters

Engine
Engine model
Cummins QSB6.7
Rated power
122/2000 kW/rpm
Max.torque
732/1500 N·m/rpm
Displacement
6.7 L
Emission standard
Tier 4 Final / EU Stage IV
Operation Range
Operating weight
22600 kg
Max. digging height
9570 mm
Max. dumping height
6700 mm
Max. digging depth
6600 mm
Max. vertical digging depth
5800 mm
Max. digging reach
9950 mm
Min. swing radius
3730 mm
Height at min.swing radius
7665 mm
Dimensions
Transport length
9728 mm
Transport width
2980 mm
Transport height
3440 mm
Upper width
2710 mm
Tail swing radius
2890 mm
Min. ground clearance
440 mm
Undercarriage/Working Device
Std. track shoe width
600 mm
Bucket capacity
0.9 m³
Track shoes(per side)
49
Upper rollers
2
Lower rollers
9
Track gauge
2380 mm
Track length
4450 mm
Boom length
5700 mm
Arm length
2950 mm
Performance
Travel speed
3.5/6.0 km/h
Swing speed
10.7 rpm
Gradeability
35°
Ground pressure
41.2 kPa
Tractive force
208 kN
Bucket digging force
138 kN
Arm digging force
99 kN
Service Refill Capacities
Fuel tank
340 L
Hyd tank
230 L
Engine oil
27 L
Engine coolant
27.6 L
Hydraulic System
Boom cylinder bore x stroke
120×1285 mm
Arm cylinder bore x stroke
135×1490 mm
Bucket cylinder bore x stroke
115×1120 mm
