Hot Sale Front Earthmoving Crawler Excavator Machine Sy135c in Africa

Hot sale front earthmoving crawler Excavator Machine SY135C in Africa

Feature

Powerful Engine

SY135Csmall excavatoradopts optimized engine output power, variable working modes, large-capacity fuel tank and reinforced structure, ensuring its top performance, high productivity and reliability.

High Efficiency and Low ConsumptionEngine

Theengine output power of SY135C 14.9 tonexcavatoris 77kW with increased hydraulic power and improved fuel efficiency. The 14.9 ton excavator adopts the customized engine with four cylinder, four-stroke direct-injection turbocharger, and providing strong operating power for the machine. The engine is designed with four working modes. The working mode can be changed on the monitor, which can maximize the operating efficiency and reduce the fuel consumption.

Innovative Electro-hydraulic Control System

With a dual-pump, dual-circuit constant power control system, the engine can provide a strong operating force. Optimized operation performance of the engine reduces power loss.

Large-capacity Fuel Tank with Anti-rust Treatment

The large capacity of fuel tank reduces the frequency of refueling. The interior of the fuel tank has been well treated against rusting. No rusting will occur even if the tank is soaked in oil containing water and phosphoric acid and other chemicals for a long period of time.

Parameters

Engine
Engine model
ISUZU 4JJ-FT4
Rated power
77/2000 kW/rpm
Max.torque
375/1800 N·m/rpm
Displacement
2.9L
Emission standard
Tier 4 Final / EU Stage IV
Operation Range
Operating weight
14870 kg
Max. digging height
8685mm
Max. dumping height
6180mm
Max. digging depth
5510mm
Max. vertical digging depth
4880mm
Max. digging reach
8290mm
Min. swing radius
2500mm
Height at min.swing radius
6500mm
Max.ground clearance of blade up
490 mm
Max.depth of blade down
320 mm
Dimensions
Transport length
7700 mm
Transport width
2650 mm
Transport height
2815 mm
Upper width
2490 mm
Blade height
480 mm
Tail swing radius
2205 mm
Min. ground clearance
425 mm
Counterweight ground clearance
870 mm
Undercarriage/Working Device
Std. track shoe width
600 mm
Track shoes(per side)
44
Carrier roller(per side)
1
Lower roller(per side)
7
Track gauge
1990 mm
Roller gauge
2930 mm
Boom length
4600 mm
Arm length
2500 mm
Performance
Travel speed
5.5/3.5 km/h
Swing speed
12 rpm
Gradeability
35°
Ground pressure
39 kPa
Tractive force
110 kN
Bucket digging force
93 kN
Arm digging force
66 kN
Service Refill Capacities
Fuel tank
240 L
Hydraulic tank
150 L
Engine oil
13 L
Engine coolant
22 L
Hydraulic System
Boom cylinder bore x stroke
105×990 mm
Arm cylinder bore x stroke
115×1175 mm
Bucket cylinder bore x stroke
100×885 mm
Blade cylinder bore x stroke
130×145 mm
