Chinese New Front Crawler Excavator Machinery Sy245h for Sale

Chinese new front crawler Excavator Machinery SY245H for sale

Feature

High Output, Best Choice for Mining Excavator

based on the SY245H model, the work equipment, undercarriage and frame have been reinforced to meet the rigorous requirements for mining applications.

Adopting 30T structure frame, the overall contour is concise and tough, fully shows the fortitude image of mining excavator.

Excellent Performance

With the AOCt (Auto Optimization Control Technology), the main pump can perfectly match the engine output power. This improves the working efficiency by 5%.

Through optimizing match, the utilization is improved, its stability is kept, then its digging efficiency is much better than others in its tonnage. This machine has strong power and high digging efficiency.

Superior Reliability

After 3000 hours of mining operations, the reliability is considered leading level.

According to special work condition of mine, key structure parts are used high strength steel. We have also designed and developed impact resistance structure. Adopting advanced manufacture and welding technology, process of automobile assembly line. Developing kay parts like engine, pump and valve with global famous manufacturers. Combined with long term multi-condition durable system certification, this machine has stable quality and high reliability.

Parameters

Engine
Engine model
Mitsubishi DO6FRC-TAA
Rated power
147/2100kW/rpm
Max.torque
750/1350Nm/rpm
Displacement
6.3L
Emission standard
Tier 3
Operation Range
Operating weight
25500kg
Max. digging height
9745mm
Max. dumping height
6715mm
Max. digging depth
6705mm
Max. vertical digging depth
5675mm
Max. digging reach
10225mm
Min. swing radius
3800mm
Height at min.swing radius
3915mm
Dimensions
Transport length
10290mm
Transport width
3190mm
Transport height
3255mm
Upper width
3045mm
Cab height
3255mm
Tail swing radius
3105mm
Min. ground clearance
470mm
Undercarriage/Working Device
Std. track shoe width
600mm
Bucket capacity
1.3m³
Track shoes(per side)
49
Upper rollers
2
Lower rollers
9
Track gauge
2590mm
Track length
4445mm
Boom length
5.9m
Arm length
2.9m
Performance
Travel speed
5.4/3.4kM/h
Swing speed
10.6rpm
Gradeability
70%/35°
Ground pressure
53.2kPa
Tractive force
227kN
Bucket digging force
175kN
Arm digging force
120kN
Service Refill Capacities
Fuel tank
475L
Hyd tank
239L
Engine oil
29L
Engine coolant
31L
Hydraulic System
Boom cylinder bore x stroke
135×1305mm
Arm cylinder bore x stroke
140×1660mm
Bucket cylinder bore x stroke
130×1156mm
