Sany Sy750h 75 Ton Mining Crawler Hydraulic Excavator

SANY SY750H 75 Ton Mining Crawler Hydraulic Excavator

Product Description

Excellent performance

10% higher work efficiency with 10% lower consumption, huge digging force, specially designed for mining working condition.more smooth operation.

Super adaptation

More than 20 kinds of optional working deivices, good protection of the engine with multiple filtration system, independent oil radiator to keep proper working temperature.

Longer lifetime

By comprehensive testing system, the designed lifetime reaches 25000 hours, 15% less pressure of key compents compared with 40 tonage models, but 30% longer lifetime.

Low maitenance cost

Much more convenient maintenance operation, durable oil and filters to make longer maitenance period, 50% less expense.

Engine	Rated power	377/1800 kW/rpm
Operation Range	Operating weight	89900 kg
	Max. digging height	11062mm
	Max. digging depth	7605mm
	Max. dumping height	7235mm
	Max. vertical digging depth	4313mm
	Max. digging reach	12037mm
	Min. swing radius	5520
	Height at min.swing radius	9780
Dimensions	Transport length	12865mm
	Transport width	4030mm
	Transport height	4855mm
	Upper width	3460mm
	Tail swing radius	4220mm
	Min. ground clearance	880mm
Undercarriage/Working Device	Std. track shoe width	600 mm
	Bucket capacity	4.2 m³
	Track length	5865mm
Performance	Travel speed	4.5/2.9 km/h
	Swing speed	7.3rpm
	Gradeability	70%35°
	Ground pressure	131kPa
	Bucket digging force	672kN
	Arm digging force	792kN

------------------
