Sany Sy500h 50ton Mining Crawler Hydraulic Excavator
- Price can be negotiated
- 1 Unit
- 32 Unit
- 14 days
Product Description
Several attachments and work tools are available to satisfy European and American high-end market demand.
Multiple counterweight weights available. Easily removable to satisfy various transportation regulations and requirements.
The new generation Cummins engine meeting T4F emission standards of the European and American markets.
Operator selectable work modes and all aspects ofthe machine configuration can be displayed on the operator monitor screen for operator convenience.
The widened, heated suspension seat was carefully selected based on many hours of operator feedback.
| Engine | Engine model | Cummins QSB12 |
| Rated power | 298/2100 kW/rpm | |
| Max. torque | 2034/1400 N.m/rpm | |
| Displacement | 11.8 L | |
| Emission standard | Tier 4Final /EU Stage IV | |
| Operation Range | Operating weight | 50100 kg |
| Max. digging height | 10929 mm | |
| Max. digging depth | 7705 mm | |
| Max. dumping height | 7647 mm | |
| Max. vertical digging depth | 6278 mm | |
| Max. digging reach | 12035 mm | |
| Min. swing radius | 5216 mm | |
| Height at min.swing radius | 9103 mm | |
| Dimensions | Transport length | 12103 mm |
| Transport width | 3596 mm | |
| Transport height | 3874 mm | |
| Upper width | 3290 mm | |
| Tail swing radius | 3765 mm | |
| Min. ground clearance | 560 mm | |
| Undercarriage/Working Device | Std. track shoe width | 600 mm |
| Bucket capacity | 2.2 m³ | |
| Upper rollers | 2 | |
| Lower rollers | 9 | |
| Track gauge | 2740 mm | |
| Track length | 5440 mm | |
| Boom length | 7000 mm | |
| Arm length | 3350 mm | |
| Performance | Travel speed | 5.2/3.0 km/h |
| Swing speed | 8 rpm | |
| Gradeability | 35° | |
| Ground pressure | 84.5 kPa | |
| Tractive force | 339 kN | |
| Bucket digging force | 200 kN | |
| Arm digging force | 223 kN | |
| Service Refill Capacities | Fuel tank | 680 L |
| Hyd tank | 480 L | |
| Engine oil | 34 L | |
| Engine coolant | 23.2 L | |
| Hydraulic System | Boom cylinder bore xstroke | 165(115) x1590 mm |
| Arm cylinder bore xstroke | 190(130) x1850 mm | |
| Bucket cylinder bore xstroke | 170(120) x1305 mm |
------------------
