XCMG 9ton Lw900kn Large Wheel Loader

LW900KN Large 9ton Wheel Loader Main Character

High productivity and low fuel consumption
High performanceQSM11(Tier3) engine.
Low fuel consumption.
import transmission with KD function.
Efficient hydraulic system.
Enlarged bucket capacity.
Long wheel base.

Comfortable work environment
Automatic electro-hydraulic transmission.
Low noise punched type cab.
Adjustable brake system.
Single lever clutch system.
Air conditioner.
Adjustable steering column.

Items	Unit	Parameters
Rated bucket capacity	m3	5
Rated load	kg	9000
Operating weight	kg	29500
Max. traction	kN	245
Max. breakout force	kN	260
Boom lifting time	s	7
Total time of 3 devices	s	12.5
Tyre		29.5R25
Overall dimension	mm	9400*3500*3770

Engine model	QSM11-C335
Type	Water cooling, 4 stroke
Suction	Turbo charging, air intercooler
Cylinder amount	6
Cylinder bore
Piston displacement	10.8L
Speed controller	Electronic, whole process speed control
Power	250kW(335HP)
Rated revs	2100rpm
Fuel system	Direct injection
Max. torque	1647nm@1400rmp
Lubrication system	Gear pump forced lubrication
Filter	Full flow type
Air filter	(double element, dust discharge and dust indicator) dry type
Hydraulic torque converter
Type	Single stage, 2 phase, 3 elements
Transmission
Type	Planetary gear
Travel speed km/h
Drive system	4WD
Front wheel	Fixed, full floating type
Rear wheel	Central pin bearing, full floating type, 26° swing
Reduction gear	Spiral bevel gear
Differential gear	Common gear
Final drive	Planetary gear, first stage reduction
Service brake	Full hydraulic wet type disc brake (4 wheels)
Parking brake	Wet type disc brake
Emergency brake	Also used as parking brake
Type	Articulation, full hydraulic power steering
Steering angle	bidirectional 40°
Min. turning radius(by outer wheel center)	6200mm
