Shuttle Personnel Carrier (EG6220K, 22seats)

The Electric Bus (Personnel Carrier) produced by Suzhou Eagle has anice quality, fashionable and comfortable design.It can be used in places like touriest spot, park, large amusement land, all-closed community, campus, hotel, resort, garden, downtown walking street, airport, port dock etc.
Model:EG6220K
System:72V/5KW Series
Battery:24xT105(185Ah@5hr rate)
Motor:10KW Chinese motor for 60minutes
Controller:Curtis 1209 (400A@2minutes)
Passenger capacity 22
Range (loaded) based on flat road at aspeed of 20km/h(km):>60
Max.Speed:40
Minimum turning radius (m):6.5
Max.Climbing ability (loaded):25%
Max.Movement after brake:≤ 4m
Max.Loading weight:1500kgs
Net weight:2500kgs
Overall dimensions (mm):5280x1955x2100
Min.Ground clearance (mm):165
Wheelbase (mm):3200
Front wheel tread (mm):1692
Rear wheel tread (mm):1700

Any specific request, please feel free to contact us by phone or by email.
