2015 New Dongfeng 25cbm Oil 6X4 Fuel Tank Truck

2015 new Donfeng Fuel Tank Truck 25CBM Fuel tank Truck 6X4 Fuel Tank truck

Quick Details

1.Capacity Volume:25CBM
2.Horse Power:210HP
3. GVW.:25000kg
4.Overall Dimensions:11000x2500x3500mm
5. Transport Medium:Fuel ,Oil,Petrol.chemical liquid


1> With multiple baffle plates in the tank, the tank has theadvantages of high intensity, stability, transporting safety etc.
2> Oil pump is installed to suck or discharge oil, with high suction pressure and speed.
3> According to users' needs, the tank can be designed as a single compartment orseveral compartments to contain different oils.
4> According to users' needs, the side or the rear of the tank can be installed1 to 3 self-flowing valves.
5> According to users' needs,the tank panting color can be customized.


PACKAGING & SHIPPING

1, Naked or waxed .
2, Delivery time: 30 days after receiving payment in advance.
3. By RORO or Bulk ship.


Service
The extremely considerate and sincerely service would be provided to our customers immediately . This including:
1.Operator Training;
2.Spare Parts Supply.
3.Life-long Technical-support.

FAQ


Q:What is your payment term?
A:We accept payment by T/T,L/C.

Q :How many trucks do you sell in 1 year?
A :Almost 20000-30000sets

Q:Is your factory a manufacturer or trading company?
A:we are the manufacturer , we are the biggest special trucks factory in china special truck base.

Q:Where is your factory located,can we visit your factory?
A: Our factory is located in South Suburb Chengli Auto-mobile Industry Park,suizhou city,Hubei Province,China,nearby Wuhan airport,we sincerely welcome you to visit!


Contact Information

Sale Manager:Yuki
Tel/Fax: 0086-27-83796298
Mobile :+008613872880232
+008618858011948

Technique Parameters

Description	DonGFENG 20CBM 6X4 Fuel tank Truck
Drive Model	6X4
Chassis	EQ1250
Number of axles	3
Vehicle Main Dimensions	Dimensions(L x W x H)(mm)		11000×2500×3500
	Wheel base (mm)		5400+1300
	Overhang (front/rear) (mm)		1250/2900
	Wheel track (front/rear) (mm)		2005,1860/1860
	Approach/Departure angle(°)		25/15
Weight in KGS	Curb Weight		10325
	GVW.		25000
Max. driving speed(km/h)			80
Engine	Model		ISDe210 40
	Type		4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
	Horse Power(HP)		210HP
	Emission standard		EuroIV
	engine capacity(ml)		6700
Gearbox	8 forwards & 1 reverse
Clutch	Reinforced diaphragm clutch
Steering Gear	Power steering, hydraulic steering with power assistance
Fuel tank (L)	250
Tire	10.00R20 tire , 10 + 1(spare)
Brakes	dual circuit compressed air brake
Tank
Material	Q235A Carbon steel
Medium	Oil
Loading Capacity (m³)	21.71
Overall dimensions(mm)	8150×2300×1600
Thickness(mm)	6
The back of the protective	section size (mm)	100×50×5
	ground height (mm)	520
ABS model	3631010-C2000
optional Equipment	Tank can be separated to several unattached small tanks to fill different fuels Tank material: carbon steel,stainless steel,FRP etc. Tank shape: Roundness , quadrate , oval Oil pump: self-priming pump,gear pump Oil meter:single,double,Fiscal processor
Standard Equipment	Equipped with valves and pipes,a set of Fuel Dispenser Equipped with a ladder on tank Install with the motion of the satellite positioning function recorder Using front coil brake and installation of ABS and the chassis front muffler

Company Information
Chengli Special Automobile Co, ltd which is appointed by Ministry of Industry and Information Technology of China,We are a Professionalmanufacturerand exporter which is concerned with the design, development and production of more than300kinds of trucks.
Our company cooperates with famous chassis manufactureer, such asDONGFENG, FAW,SINOTRUK, JAC, SHACMAN, FOTonand etc.
Chengli take customer's satisfaction as the top requirement. All of the trucks and semi-trailer sell toAfrica, South-east Aisa, Australia, Middle-eastand other place.They mainly from below country:Angola,Algeria,Kenya,Nigeria,Rwanda,Sudan,Zambia,Libya,Congo, Indonesia, Malaysia, Philippines,Vietnam,Turkey,Yemen,Syria.


ChengliSpecialautomobileCo.,Ltdalsoprovideproductsasfollows:

1.LPGTankTruckTrailer/FuelTankerTruck
2.Watertruck/WaterTankTruck/WaterSprinklerTruck/WaterTanker
3.Truckwithcrane/Truckmountedcrane
4.DumpTruck/TipperTruck/SideTipper/EndTipper
5.FireFightingTruck/FireTruck/FireVehicle
6.ConcreteMixerTruck
7.Vantruck/Blastingequipmenttransporter/Refrigeratedtruck
8.Fecalsuctiontruck/Sewagesuctiontruck,
9.CementPowderTanktruck/Bulkcementtruck
10.High-altitudeoperationtruck,
11.Self-loadinggarbagetruck,garbagecompactortruck,sealedgarbagetruc
12.Tractor
13.HighPressureCleaningTruck
14.SweeperTruck
15.SemiTrailer(flatbedtrailer/skeletontrailer/dumpsemitrailer/sidewalltrailer/lowbedtrailer/vancontainertrailer/warehousetrailer,etc.)



2015 new Donfeng Fuel Tank Truck 25CBM Fuel tank Truck 6X4 Fuel Tank truck

Welcom to visit our factory!
