Propane LPG Gas Tank 25metric Ton LPG Storage Tank
- USD 17700.21 /Unit
- 1 Unit
- 69 Unit
- 14 days
Product Description
Propane LPG Gas Tank 50cbm lpg storage tank
1. Our LPG product: LPG tanker (5cbm to 120cbm); LPG container tank (20ft, 40ft); LPG semitrailer
2. New design: Attractive appearance and safety in usage
3. Certificate ISO9001 and 3CWe're expecting friends from all over the world to come to visit our factory.
4. High quality& resonable price
LPG tank container brief detail:
1)Designing pressure:0.7~2.16Mpa Designing temperature:500C
2)The various types LPG tanker is researched and manufactured by stress analysis design and has obvious advantage of large capacity.light weight and high efficiency.
3)We inspect the quality of product strictly,ensure that A and Btype of welding seam pass the examination of level two radiographic test,C and D type of welding seam pass the examination of level one radiographic test.
4)There are domestic or imported safety accessories with high quality ,its matching is complete.
5)The anticorrosion coating of LPG tanker adopt the following process, sandblast, spray painting ,purging and so on
Parameter of the LPG storage tank
about US
Chengli special automobile Co., Ltd is anautomobile manufacturer, the company is a marketing enterprise of various heavy automobile brands, integrating international and domestic trade. Besides, the company has established a good relationship with domestic and overseascustomersfromAfrica, South America, theMiddle Eastand South Asia, winning a universal recognition and trust from the oversea customers and contributing to China trucks' entrance to the international market.
1.Quality control: our company truck pass ISO,CCC,BVcertification.
2.Design capacity :Our factory have over200technicians and designers.
3. Exhibition: our factoryattendCanton Fairevery year.
4.Export market: Africa, Southeast Asia, Central Asia, South America , Oceania and so on.
5.Our company cooperate with famous chassis manufacturers, such asDONGFENG,FAW, SHINOTRUK,IVECO, FOTON,and etc.
ChengliSpecialautomobileCo.,Ltdalsoprovideproductsasfollows:
1.LPGTankTruckTrailer/FuelTankerTruck
2.Watertruck/WaterTankTruck/WaterSprinklerTruck/WaterTanker
3.Truckwithcrane/Truckmountedcrane
4.DumpTruck/TipperTruck/SideTipper/EndTipper
5.FireFightingTruck/FireTruck/FireVehicle
6.ConcreteMixerTruck
7.Vantruck/Blastingequipmenttransporter/Refrigeratedtruck
8.Fecalsuctiontruck/Sewagesuctiontruck,
9.CementPowderTanktruck/Bulkcementtruck
10.High-altitudeoperationtruck
Ourclients
Payment andPackaging &Shipping
1.30% deposit after order /confirm/iation, 70% balance should be paid before delivery.All byT/T, L/C.
2.Delivery time:30 working daysafter payment is received.
3. By RORO or Bulk ship.
Contact Us
1. Our LPG product: LPG tanker (5cbm to 120cbm); LPG container tank (20ft, 40ft); LPG semitrailer
2. New design: Attractive appearance and safety in usage
3. Certificate ISO9001 and 3CWe're expecting friends from all over the world to come to visit our factory.
4. High quality& resonable price
LPG tank container brief detail:
1)Designing pressure:0.7~2.16Mpa Designing temperature:500C
2)The various types LPG tanker is researched and manufactured by stress analysis design and has obvious advantage of large capacity.light weight and high efficiency.
3)We inspect the quality of product strictly,ensure that A and Btype of welding seam pass the examination of level two radiographic test,C and D type of welding seam pass the examination of level one radiographic test.
4)There are domestic or imported safety accessories with high quality ,its matching is complete.
5)The anticorrosion coating of LPG tanker adopt the following process, sandblast, spray painting ,purging and so on
Parameter of the LPG storage tank
| Item | Parameter | ||
Tank | Description of LPG tank | 50CBM LPG storage tank | |
| Overall dimensions (mm) | 11508*2428*3018 | ||
| Curb weight(kg) | 11140 | ||
| Filling weight(kg) | 19950 | ||
| Type of vessel | The third kind | ||
| Design pressure | 1.77MPa | ||
| Max working pressure | 1.61MPa | ||
| Design temperature | -19~50ºC | ||
| Filling medium | Liquid petroleum gas (propane) | ||
| Corrosion allowance | 1.0mm | ||
| Volume | 50 CBM | ||
| Thermal treatment | The entirety | ||
| Filling capacity | 420~450kg/CBM | ||
| Material of the tank | Q345R | ||
| Hydraulic test pressure | 2.22 M Pa | ||
| Gas tight test pressure | 1.77 M Pa | ||
| Cylinder thickness | 14mm | ||
| Head thickness | 14mm | ||
| Service time | 10 years | ||
| Accessory for the LPG storage tank | |||
| Liquid level indicator | Type | UNZ-518C14 | |
| Version of the indicator | Magnetic type liquid level indicator | ||
| Normal pressure | 2.5M Pa | ||
| Scope of testing | 50-2300mm | ||
| Precision | 2.5 | ||
| Safety valve | Model | A42F-2.5-80 | |
| Version | Built-in | ||
| Normal pressure | 2.5 M Pa | ||
| Normal diameter | DN80 | ||
| Opening pressure | 1.68~1.76M Pa | ||
| Re-seating pressure | >=0.8 times of the opening pressure | ||
| Loading and unloading system | Normal diameter | Feed pip | DN50 |
| Drain pip | DN50 | ||
| Admission port | DN50 | ||
| Sewage outfall port | DN50 | ||
| Vent nozzle port | DN50 | ||
| Standard | GB150 <pressure vessel> TSG R0004-2009 | ||
| Safety fitting for selection | Safety valve, column magnetic liquid level gauge, pressure gauge, thermometer, cut-off valves, etc. | ||
| Specification | Designed Pressure: 1.66Mpa Filling Ratio: 0.42 kg/L Working Temperature:-50ºC Corrosion Allowance: 1mm | ||
| Payment term | 30%T/T paid in advance, 70%T/T paid before delivery | ||
