XCMG Official Xe225QA-I 22ton Crawler Excavator (more models for sale)

XCMG XE225QA-I22ton crawler excavator (more models for sale)
1. XCMGXE225QA-I20toncrawler excavator
XE225QA-I
Rated Power:
106.5kW 143HP @1,950rpm
Operating Weight:
22,000kg 48,501lb
Bucket Capacity:
1.0m3 1.31yd3
2. XCMGXE210B20toncrawler excavator
Rated Power:
106.5kW 143HP @1,950rpm
Operating Weight:
21,500kg 47,399lb
Bucket Capacity:
0.93m3 1.22yd3
3. XCMGXE210F20toncrawler excavator
Rated Power:
116kW 155.6HP @2,000rpm
Operating Weight:
21,500kg 47,399lb

Advanced hydraulic system
Strong configuration
CE,ISO certification
In stock

Model	Unit	Parameter
Operation weight	kg	21140
Bucket capacity	m³	0.86
Engine
Model	/	QSB6.7
Rated power	kw/rpm	129/2200
Max.torque	N.m	799
Displacement	L	6.7
Fuel tank	L	305
Main performance
Rated flow	L/min	220
Working pressure	Mpa	32
Hydraulic tank	L	202
Rotating speed	r/min	13
Bucket digging force	kN	115
Arm crowd force	kN	91
Min.swing radius	mm	6500
Travel speed	km/h	9.5/31
Grade ability	°	35°
Hydraulic system
/Pump/Pilot pump	/	Tow ram pumps
Apperance size
AOverall length	mm	9135
BOverall width	mm	2552
COverall height	mm	3370
DGround clearance of counterweight	mm	1250
EMin.ground clearance	mm	340
FTail swing radius	mm	2820
GWheel base of crawler	mm	2850
HTumbler distance	mm	1890
Iwidth of chassis	mm	2495
JDistance bttween the front axle and center rotation	mm	1550
KHeight of engine hood	mm	2542
LMax.dozer cutting depth	mm	145
MMax.dozer lifting height	mm	479
(/)Dozer(width/height)	mm	2467/566
Working scope
AMax.digging radius	mm	9613
BMax.ground digging distance	mm	9380
CMax.digging height	mm	10528
DMax.dumping height	mm	7530
EMax.digging depth	mm	5755
F8Digging depth at the range of level 8 feets	mm	5580
Standard configuration
Length of bucket arm	mm	2910
Bucket capacity	m³	0.86
