XCMG Xe135b 13ton Crawler Excavator (more models for sale)

XCMG XE135B 13ton crawler excavator (more models for sale)
Rated Power:
72.7kW 97.5HP @2,200rpm
Operating Weight:
13,000kg 28,660lb
Bucket Capacity:
0.52m3 0.68yd3

XCMG XE135BL 13ton crawler excavator (more models for sale)
Rated Power:
72.7kW 97.5HP @2,200rpm
Operating Weight:
13,500kg 29,762lb
Bucket Capacity:
0.52m3 0.68yd3

Advanced hydraulic system
Strong configuration
CE,ISO certification
In stock

		Unit	Parameters
Model	Operating weight	Kg	13000
	Bucket capacity	M³	0.4~0.52
Engine	Engine model	/	ISUZU BB-4BG1TRP
	Direct injection	/	√
	4x strokes	/	√
	Water cooling	/	√
	Turbocharging	/	√
	Cylinders	/	4
	Output power of engine	KW/rpm	72.7/2200
	Max torque/speed	N.m/rpm	337.6/1600
	Displacement	L	4.329
Main performance	Travel speed	Km/h	5.16/3.03
	Slewing speed	r/min	12.3
	Gradient capability	°	≤35°
	Ground pressure	KPa	40
	Digging capacity of bucket	KN	85
	Digging capacity of bucket rod	KN	65
	Max traction force	KN	134
Hydraulic system	Main pump	/	Two plunger pumps
	Rated flow of main pump	L/min	2x123
	Pressure of main sadety valve	MPa	31.4/34.3
	Pressure of traveling system	MPa	34.3
	Pressure of swing system	MPa	25
	Pressure of pilot system	MPa	3.9
Oil volume	Fuel tank capacity	L	250
	Hydraulic tank capacity	L	130
	Engine oil volume	L	14

XCMG was born in 1943 as an arsenal workshop during the War Against Japanese Aggression and has a history of 72 years.The group was incorporated in 1989, and has kept its leading position in Chinese construction machinery industry for 26 years.If you want know more about us, you can also visit our web site: http://www.xcmg.com/en-mena/.

According to KHL's Yellow Table, XCMG ranks No.8 in the world construction machinery industry in 2014.According to the rank of Top50 Summit of World Construction Machinery Industry, XCMG ranks No.5 in the world.

At present, XCMG is a large state-owned international corporation with the most complete range of products and over 30,000 employees operating in China, America, Germany, Netherlands, Poland, India, Brazil and Uzbekistan.

The goal of XCMG is to become a leading world-class enterprise with great value creativity.
