JAC Light CBU Truck Hfc1063k E600 Rhd

1.Original parts2.Good quality3.Quick quotation4.Reasonable price5.Best serviceHFC1063K E600 RIGHT HAND DRIVETruck part,spare part,engine part,part.Light truck engine model:YSD490Q HFC4DA1 HFC4DA1-1 HFC4DA1-2B HFC4DA1-2B1CY4102BQ C4110 CY4102BZQ CY4102BQ CY4102BZLQ CY4102BQ YZ4105QFCA4DF2 YZ4108Q YC4E140-33Light truck transmission model:LG515 LG5-20E30 LG5-20E27 JAC MSB-5M JAC MSB-5N LC5T30 LC5T46 LC5T97LG5-30 QHS5-30 LC6T46 All of them euqipped by JAC light truck:HFC1020 SERIES,HFC1040 SERIES,HFC1045 SERIES,HFC1048 SERIES,HFC1061 SERIES,HFC1063 SERIES,HFC1083 SERIES,HFC3040 SERIES,HFC3041 SERIES,HFC3048 SERIES,HFC3072 SERIES.Heavy truck engine model:WD615.56 260HP YC6M280-20 280HPWD615.50 290HPWD615.31 310HPYC6M320-20 320HPWD615.46 360HPISM380E 20 380HP ISM440E 20 440HPHeavy truck transmission model:CA6T123-85 6J80T 8JS105T 9JS119 12JS160 RT11509F 12JS180 F6J95TB LC6T160 8JS118TC 9JS150T-B All of them euqipped by JAC Heavy duty truck:HFC1131KR1,HFC1251KR1 SERIES,HFC3251KR1 SERIES,HFC3311KR1 SERIES,HFC4251KR1 SERIES,HFC5255GJB SERIES.

Specification
Model	HFC1063K
Serious Number	E600
Cabin	Single Cab
Engine	CY4102BZQ
Type	in line-4, turbocharged, diesel
Displacement (cc)	3856
Compression Ratio	17
Max Power (HP/rpm)	110/2800
Max Torque (N.m/rpm)	323/1600
Transmission	LC5T30
Speed Ratio	4.776,2.496, 1.429,1, 0.728,R4.774
Gear Position	R 2 4 1 3 5
Final gear ratio	E4QZ-m0-6.142
Brake system	air brake
Tyre	8.25-16
Overall Dimensions(mm(L*W*H)	7285*2170*2216
Cargo Dimensions(mm)(L*W*H)	5530*2010*550
Tread (front / rear )(mm)(/)	1665/1600
Wheelbase(mm)	4150
Curb Weight (kg)	3850
Max Load Capacity(kg)	4000
Gross Vehicle Weight(kg)	8045
Min Turing Radius(m)	8
Min Ground Clearance(mm)	210
Max Speed(km/h)	95
Seating Capacity	3
Max Gradeability(%)	32
frame Section Size(mm)	230*75*6
Configuration
Air Conditioner	√
Power Steering	√
Pre-heater	×
Wind deflector
Sidebumper	√
Rear bumper	√
Power Assist of the clutch
Reverse Annunciator
Digital Radio
Exhaust Braking	√
New model cabin 808
Else
Remark:
√:Standard Equipment :Optional Under develop ×:Not Available
ONE ConTAINER CAN LOAD 2UNITS
All information subject to change
