JAC Light CBU Truck Hfc1020k D8701 Rhd
- Price can be negotiated
- 1 Unit
- 12 Unit
- 20 days
Product Description
1.Original parts2.Good quality3.Quick quotation4.Reasonable price5.Best serviceHFC1020K D8701 RIGHT HAND DRIVETruck part,spare part,engine part,part.Light truck engine model:YSD490Q HFC4DA1 HFC4DA1-1 HFC4DA1-2B HFC4DA1-2B1CY4102BQ C4110 CY4102BZQ CY4102BQ CY4102BZLQ CY4102BQ YZ4105QFCA4DF2 YZ4108Q YC4E140-33Light truck transmission model:LG515 LG5-20E30 LG5-20E27 JAC MSB-5M JAC MSB-5N LC5T30 LC5T46 LC5T97LG5-30 QHS5-30 LC6T46 All of them euqipped by JAC light truck:HFC1020 SERIES,HFC1040 SERIES,HFC1045 SERIES,HFC1048 SERIES,HFC1061 SERIES,HFC1063 SERIES,HFC1083 SERIES,HFC3040 SERIES,HFC3041 SERIES,HFC3048 SERIES,HFC3072 SERIES.Heavy truck engine model:WD615.56 260HP YC6M280-20 280HPWD615.50 290HPWD615.31 310HPYC6M320-20 320HPWD615.46 360HPISM380E 20 380HP ISM440E 20 440HPHeavy truck transmission model:CA6T123-85 6J80T 8JS105T 9JS119 12JS160 RT11509F 12JS180 F6J95TB LC6T160 8JS118TC 9JS150T-B All of them euqipped by JAC Heavy duty truck:HFC1131KR1,HFC1251KR1 SERIES,HFC3251KR1 SERIES,HFC3311KR1 SERIES,HFC4251KR1 SERIES,HFC5255GJB SERIES.
Specification | |
Model | HFC1020K/KR1 |
Serious Number for produce | D8701 |
Cabin | Single/King Cab |
Engine | HFC4DA1 |
Type | in line-4,diesel |
Displacement(cc) | 2771 |
Compression Ratio | 17 |
Max Power (HP/rpm) | 77/3600 |
Max Torque (N.m/rpm) | 174/2100-2300 |
Transmission | JAC MSB-5M |
Speed Ratio | 5.529,2.782, 1.641,1, 0.785,R5.271 |
Gear Position | 1 3 5 2 4 R |
Final gear ratio | D870-6.142 |
Brake system | hydraulic brake |
Tyre | 6.50-16 |
Overall Dimensions(mm)(L*W*H) | 5748*1868*2170 |
Cargo Dimensions(mm)(L*W*H) | 3580/3250*1770*370 |
Tread (front /rear )(mm)(/) | 1440/1395 |
Wheelbase(mm) | 2800 |
Curb Weight (kg) | 1800 |
Max Load Capacity(kg) | 1700 |
Gross Vehicle Weight(kg) | 3630 |
Min Turing Radius(m) | 6 |
Min Ground Clearance(mm) | 185 |
Max Speed(km/h) | 90 |
Seating Capacity | 2 |
Max Gradeability(%) | 30 |
frame Section Size(mm) | 170*70*5 |
Configuration | |
Air Conditioner | |
Power Steering | |
Pre-heater | |
Wind deflector | |
Sidebumper | √ |
Rear bumper | |
Power Assist of the clutch | × |
Reverse Annunciator | × |
Digital Radio | |
Exhaust Braking | √ |
New model cabin 808 | CD, |
