Flatbed Two Axle Semi Trailer with Gantry

Flatbed Semi Trailer with Gantry


Product Description
1. Tare Weight: about 8.5-13T
2. Dimension: 13000x3000/3500x1650 mm
3. Loading Capacity: 40T-100T
4. Axle: 13 T/16T
5. Rim: 6.5-20/7.5-20/8.00-20/8.5-20
6. Tire: 8.25R20/10.00R20/11.00R20/12.00R20
7. Suspension: Mechanical suspension Or Air suspension
8. Spring leaf: 90(W)mmx13(Thickness)mmx10 Layer or 100mmx12mmx12
9. King pin: JOST brand 2.0 or 3.5inch bolts type or Welding type
10. Support leg: JOST brand D200T or China brand 28Tons (Double speed)
11. Main beam:
Height: 450mm-520mm,
Hpper plate is 14mm-25mm,
Middle plate is 8mm-12mm,
Down plate is 16mm-25mm;
12. Material: Q345B Steel.
13. Side beam: 16mm -25mm channel steel ( Material is Q235steel ).
14. Ladder: Manual or Hydraulic type
15. Gooseneck: For choose
16. Brake chamber: WABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); Two pieces of 45L air tanks
17. ABS: Optional
18. Twist Locks: Four, Eight or Twelve pieces (Lifting type or Twist Screw Type)
19. Valve: WABCO valve
20. Light: LED light
21. Voltage: 24V
22. Receptacle: 7 ways (7 wire harness)
23. Tool box: One piece, 1m× 0.5m× 0.5m (Size can be choose freely)
24. Equipped: 1 unit Tire spanner, 1 unit gudgeon sleeve and 1 unit cranking bar
25. Painting: Complete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
26. Shipping Terms: By bulk cargo carrier, RORO or 40HQ container.

SPECIFICATION
Main frame	Heavy duty and extra durability designed; Opting for high tensile steel Q345B, welding by automatic Submerged-Arc processes 500mm Height "I" beam, Top Flange 14mm, width 140mm; Middle Flange 6mm; Bottom Flange 16mm, width 140mm
Floor	Steel sheet 3mm thickness
Axle and suspension	L1-32Ton Bogie Suspension Assembly
King Pin	one unit of 2" bolt-in kingpin
Landing Gear	Two-speed, manual operation, heavy duty SAF 19" linked landing gear
Wheel Rim	9 units of 9.00-22.5 rim, including 1 unit spare rim
Tire	9units of 12R22.5 tubeless tyre, including 1 unit spare tire
Twist Lock	Twelve nos. four nos are fasten mode, eight nos are up-down mode, of ISO twist lock for 2x20ft, 1x40ft container, central locks can be laid down.
Spare Wheel Carrier	One set of spare wheel carrier including a riser.
Pneumatic Braking System	Two units of WABCO RE 4 relay valve; four units of T30/30 spring brake chamber; two units of T30 brake chamber, two units of reliable local brand 45L air tank; two units of reliable local brand standard coppery air-connector.
Electrical System	One unit of JAEGER POWAY, 24V 7-pin ISO 1185 socket; two sets of reliable, local brand standard rear light, turn light, rear reflector, side light, side reflector etc. One set of DAFA(brand) 6-core standard Cable.
Painting	Sand blasting before painting; one coats of primer, anti corrosion; two coat of finish painting; colour advised by client
Accessory	One box with a set of standard trailer tool

WHY you trust and choose us?

1. Complete production line, from trailer Design to Delivery.

2. ISO 9001: 2008 and CCC quality certificate.

3. Use 100% famous brand spare parts in China for our products.

4. OEM/ODM service. Just tell us your idea, our R&D team is standing by.

5. We are trusted by the clients from Africa, Australia, South America, Indonesia and so on.

6. We accept 100% inspection, welcome to our factory at any time.
