420HP Sinotruk HOWO 6X4 Tractor Truck

Tractor Specification
Sinotruk HOWO heavy duty truck tractor 6X4
(1) Driving style: 4X2, 6X4,
(2) Cab: HW70, HW76,HW79
(3) Engine: 266HP,290HP, 336HP, 371HP,380HP,420HP
(4) Emission: EUROII, EUROIII, EUROIV, EUROV
(5) Can accept small order



CCC/SGS Approved Sinotruk Howo 6x4 Tractor Truck

Cabin	Driving Type: 6×4 Model: ZZ4257S3241W(380hp)
	HOWO 76, standard cab. With single sleeper with air conditioner as attached photo for ref.
Vehicle Main Dimensions	Overall Dimensions(L×W×H)mm	6800×2496×2960
	Wheel base (mm)	3225+1350
	Rear wheel Track (mm)	1830
	Approach/Departure Angle (°)	16/70
	Tare Weight(kg)	9180
	Loading Weight(kg)	15820
Tyre	Eleven units of 12.00-20 Tubeless tyre.
Front Axle	HF7 drum wheel axle, Rigid steering with double-T cross section beam.
Rear Axle	HW1697 double reduction drive axle, speed ratio:4.22
Air Cleaner	Bath air cleaner type
Max. Driving Speed (km/h)		95
Engine	Brand	SINOTRUCK
	Type	WD12.38
		6-cylinder in-line with water cooling; 4-strole direct injection; Turbo-charging and inter-cooling
	Rated output	380hp option:266hp290hp336hp371hp380hp420hp
	Emission Standard	Euro II
	Bore x Stroke	126x155(mm)
Gearbox	HW19710, Ten block transmission, ten forward & two reverse. speed ratio:14.28,Torque: 1900Nm
Clutch	Reinforced diaphragm clutch, diameter 430mm
Steering Gear	ZF8098,original made in German.
Fuel Tank (L)	Standard 300L(option: 400L450L)
Brake	Service brake: dual circuit compressed air brake; Parking brake: compressed air operating on rear wheels; Auxiliary brake: engine exhaust valve brake
