Sinotruk HOWO 6X4 Euro 4 Heavy Duty Diesel Tractor Truck

Truck Model

ZZ4257N3241V

Dimension(Lx WxH)(mm)

6800x2490x3668

Approaching /Departure angle(°)

16/70

Overhang(front/rear) (mm)

1500/700,725

Wheel base (mm)

3200+1400,3225+1350

Max speed(km/h)

102

Curb weight(kg)

11930

Loading Weight(kg)

40000

Engine

Model

D12.42,water-cooled,four strokes,

6 cylinders in line with water cooling,

turbocharged and intercooling, directly injection

Fuel type

Diesel

Horsepower

420hp

Emission

EURO2

Fuel tanker(L)

400

Transmission

Model

HW19710

Brake system

Service brake

Dual circuit compressed air brake

Parking brake

spring energy, compressed air operating on rear wheels

Steering system

Model

ZF8098

Front axle

HF9 (Steering with double T-cross section beam

Loading capacity: 9000kg)

Rear axle

HC16 (Pressed axle housing, central double reduction with
differential locks between axles and wheels)

Color

RED .

Tyre

315/80R22.511pics

King Pin

90# or 50# optional

Electrical system

Battery

2X12V/165Ah

Alternator

28V-1500kw

Starter

7.5Kw/24V

Cab

HOWO76cab, (onesleeping, with air-condition),

all-steel forward control,55ºhydraulically tiltable to the

front, 2- arm windscreen wiper system with three

speeds, laminated windscreen with casted-in radio

aerial, hydraulically damped adjustable driver's seat and

rigid adjustable co-driver's seat, with heating and ventilating system,
outer sun visor, adjustable roof flap, with stereo radio/cassette

recorder, safety belts and adjustable steering wheel, air

horn, with 4-point support fully floating suspension and

shock absorbers
