Dongfeng 6X4 Sewage Vacuum Suction & High Pressure Jetting Truck, 10, 000 Liter Sewage Suction T

Part 1: The structure of Sewage Suction Truck
1.Chassis :
a.Drive type: 4x2,4x4,6x2,6x4,6x6,8x4 etc.
b.Our factory has good business relationship with FAW,SINOTRUCK ,DonGFENG ,SHACMAN,JAC.JMC,FOTON,ISUZU,etc.
2.Tanker body:From 2m3 to 25 m3 capacity
3.Accessory of sewage suction factions:Equipped with PTO, transmission shaft, vacuum suction sewage pump, high pressure molding tank, moisture separator, gas-oil separation, multiple directional control valve, hanger rod, self-discharging valve, suck fecal gun and pipe network system.

Part 2: Our main vacuum suction trucks series & view of workshop

Part 3 : Technical date of Dongfeng sewage jetting truck
1. Technical data of the Dongfeng truck chassis

The parameters of chassis
Chassis Model	DFL1250		Driving type	6*4 left hand drive
Gross weight (kg)	25,000		Wheel base	4350+1300
Front Tread (mm)	1,986		Rear Tread (mm)	1860
Front suspension(mm)	1,460		Rear suspension (mm)	2340
Tyre	10.00-20		Tyre number	10+1(one spare tyre)
Spring number	8/9		Max speed (km/h)	90
The parameters of Engine
Engine		Manufacturer :		Dongfeng cummins
		Rated Power		245HP
		Engine type		six-cylinder, turbocharged and intercooled
		Fuel type		Diesel
		Emission standard		Euro 4

2. Technical data of the tank

Tank volume and material
Sewage tank volume	litres	12,000
Sewage tank material	/	Carbon steel Q235-A
Sewage tank thickness	mm	5
Water tank volume	litres	4,000
Water tank material	mm	304 stainless steel
Water tank thickness	mm	3
Jetting water pump
model	/	SLR212/200(Italy brand high pressure plunger pump )
Max flux	L/min	200
Working pressure	Mpa	20
Jetting high pressure pipe	/	70 meters ¢19 , hydraulic operation
Pipe Retractable wring tension	KN	≥10
Pipe winding speed	m/min	0-25
Jetting spraying nozzles	/	10 pcs carbon steel spraying nozzles
Pipe reel rotation	/	180°
Pipe reel rotation	/	Rear of tank
Vacuum pump
Model	/	PN84D (Italy brand)
Flux	L/min	9000
Max vacuum degree	/	92%
Max pressure	bar	1.5
Max power	KW	11.2
Max sewage suction depth	m	≥7.8
Other configuration
Sewage tank lifting	/	Hydraulic lifting dumping
Tank slope angle	°	≥5
Sewage pipe	mm	102
Pumping time	min	5-7
Boom length	mm	1000
Boom rotation angle	°	270
Boom lifting angle	°	0-20
Hydraulic pressure	Mpa	16
Control way	/	Manual and electronic control
Hydraulic motor	/	Chinese brand
Multi valve manufacturer	/	Chinese brand
Hydraulic pump	/	Chinese brand
Hydraulic cylinder	/	Chinese brand

Part 4: Our factory introduction and main products
HUBEI VELDLION MACHINERY CO., Ltd is an authorized forklift manufacturer.We are specialized in the production of avariety of special-purpose vehicles.
Creating value for our customers is our company's concept. Welcome to enquiry from us, Let's our sales team make you more great in this field.
Our main products:
1. LPG tank &truck %trailer
2. Fire engine truck
3. Truck mounted with crane
4. Heavy duty truck, Dump Truck
5. Water Truck,
6. Fuel tanker,
7. Van truck, insulated truck, refrigeration truck
8. Fecal suction truck, sewage suction truck,
9. Concrete mixer truck,
10. High-altitude operation truck,
11. Self-loading Garbage Truck, garbage compactor truck, sealed garbage truck,
12. Bulk Cement Truck,

Part 5: Our service
(1) More than 300 workers ,large and advanced production;
(2) Have professional engineer,can offer the best solutions;
(3) With keeping good relation with Sinotruk, FOTON, ISUZU, DFAC, FOTON, SHACMAN chassis factory.
(4) Build strict QC team to guarantee the quality;
(5) Own good sales team, can offer warm follow-up service.
